Quick Details
-
Color:
-
full color
-
Panel Size:
-
500x500mm/500x1000mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW - RB
-
Pixel Pitch:
-
2.6mm, 2.6mm
-
Brightness:
-
800≤4500nits
-
pixel density:
-
147456dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100000 hours
-
IP Rating:
-
IP31/IP65
-
Resolution:
-
192x192dots/cabinet
-
View Angle（H/V）:
-
160/160
-
Module size:
-
250x250 mm
-
Module Resolution:
-
96x96dots
-
Lamp type:
-
SMD1515
-
Scan mode:
-
1/32S
-
Cabinet material:
-
Die-casting Alumimum
-
Cabinet Weight:
-
7.5/14kg
-
Refresh rate:
-
3840Hz
-
Installation:
-
Hanging and Standing Support
-
Control system:
-
Novastar System
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
DDW
-
Color:
-
full color
-
Panel Size:
-
500x500mm/500x1000mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW - RB
-
Pixel Pitch:
-
2.6mm, 2.6mm
-
Brightness:
-
800≤4500nits
-
pixel density:
-
147456dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
1R1G1B
-
Lifespan (hours):
-
100000 hours
-
IP Rating:
-
IP31/IP65
-
Resolution:
-
192x192dots/cabinet
-
View Angle（H/V）:
-
160/160
-
Module size:
-
250x250 mm
-
Module Resolution:
-
96x96dots
-
Lamp type:
-
SMD1515
-
Scan mode:
-
1/32S
-
Cabinet material:
-
Die-casting Alumimum
-
Cabinet Weight:
-
7.5/14kg
-
Refresh rate:
-
3840Hz
-
Installation:
-
Hanging and Standing Support
-
Control system:
-
Novastar System
标题
Discover Your Right Application , Make Your Business Possible !
Common warranty in LED field is 2 years, ours is 3 years Longer warranty
periods, better after-sale services, worry-free user experience
Products Description
Specifications
|
Model
|
P1.95
|
P2.6
|
P2.97
|
P3.91
|
P4.81
|
||||
|
Module size
|
250×250mm
|
|
|
|
|
||||
|
Module resolution
|
128x128dot
|
96×96dot
|
84×84dot
|
64×64dot
|
52×52dot
|
||||
|
Scanning
|
1/32s
|
1/32s
|
1/28s
|
1/16s
|
1/13s
|
||||
|
SMD
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD2020/1921
|
SMD1921
|
||||
|
Maintenance
|
Front/Back
|
|
|
|
|
||||
|
Installation
|
Hanging/streching
|
|
|
|
|
||||
|
Cabinet size
|
500×500mm
|
|
|
|
|
||||
|
Density
|
262144dot/m²
|
147456dot/m²
|
112896dot/m²
|
65400dot/m²
|
44320dot/m²
|
||||
|
Brightness
|
≥800cd/m²
|
≥800cd/m²
|
≥800cd/m²
|
800≥6000cd/m²
|
4500cd/m²
|
||||
|
Max. Power Consumption
|
800w
|
|
|
|
|
||||
|
Average Power Consumption
|
400w
|
|
|
|
|
||||
|
Cabinet weight
|
7.5kg
|
|
|
|
|
||||
|
Cabinet material
|
Die-casting aluminum
|
|
|
|
|
||||
|
IP rate
|
IP31
|
IP31
|
IP31
|
IP31/IP65
|
IP65
|
||||
|
Grayscale
|
10000:1
|
|
|
|
|
||||
|
Refresh rate
|
≥3840Hz
|
|
|
|
|
||||
|
Frame change frequency
|
50/60hz
|
|
|
|
|
||||
|
Vertical viewing angle
|
＞140°
|
|
|
|
|
||||
|
Input Voltage
|
AC110V – AC220V
|
|
|
|
|
||||
|
Temperature-operating
|
﹣10℃～60℃
|
|
|
|
|
||||
|
Life span
|
≥100,000H
|
|
|
|
|
||||
|
Vertical viewing angle
|
＞140°
|
|
|
|
|
||||
|
Input Voltage
|
AC110V – AC220V
|
|
|
|
|
||||
|
Temperature-operating
|
﹣10℃～60℃
|
|
|
|
|
||||
|
Life span
|
≥100,000H
|
|
|
|
|
||||
