Quick Details
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
50 kN
-
Theoretical Shot Volume(cm³):
-
60 cm³
-
Injection Rate (g/s):
-
95 g/s
-
Injection Weight (g):
-
150 g
-
Screw Speed (rpm):
-
1 - 220 rpm
-
Screw diameter (mm):
-
36 mm
-
Distance between Tie Bars:
-
375x375 Mm
-
Weight (KG):
-
3250
-
Place of Origin:
-
China
-
Open Stroke(mm):
-
100 mm
-
Brand Name:
-
custom
-
Power (kW):
-
18 kW
-
Motor:
-
Servo Energy Saving Motor
-
Opening Stroke:
-
630mm
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Clamping Force (kN):
-
1080
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
50mm
-
Distance between Tie Bars(Height)(mm):
-
100mm
-
Ejector Number:
-
5
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
50 kN
-
Theoretical Shot Volume(cm³):
-
60 cm³
-
Injection Rate (g/s):
-
95 g/s
-
Injection Weight (g):
-
150 g
-
Screw Speed (rpm):
-
1 - 220 rpm
-
Screw diameter (mm):
-
36 mm
-
Distance between Tie Bars:
-
375x375 Mm
-
Weight (KG):
-
3250
-
Place of Origin:
-
China
-
Open Stroke(mm):
-
100 mm
-
Brand Name:
-
custom
-
Power (kW):
-
18 kW
-
Motor:
-
Servo Energy Saving Motor
-
Opening Stroke:
-
630mm
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Clamping Force (kN):
-
1080
Product Description
|
Screw Diameter
|
36 mm
|
|
Screw L/D Ratio
|
21 L/D
|
|
Shot Size(Theoretical)
|
165 cm3
|
|
Injection Weight(PS)
|
150 g
|
|
Injection Rate
|
95 g /s
|
|
Plasticizing Capacity (pcs)
|
16 g /s
|
|
Injection Pressure
|
183 Mpa
|
|
Screw Speed
|
0-220 rpm
|
|
Clamp Tonnage
|
1080 KN
|
|
Toggle Stroke
|
340 mm
|
|
Space Between Tie Bars
|
375x375 Mm
|
|
Max. Mould Height
|
380 mm
|
|
Min. Mould Height
|
150 mm
|
|
Ejector Stroke
|
100 mm
|
|
Ejector Tonnage
|
33 KN
|
|
Ejector Number
|
5 piece
|
|
Max. Pump Pressure
|
16 Mpa
|
|
Pump Motor Power
|
11 KW
|
|
Heater Power
|
5.9 KW
|
|
Machine Dimension(L*W*H)
|
4200x1300x1750 mm
|
|
Machine Weight
|
3.25Ton
|
Details Images
Samples
Packing & Details
Packaging Details:
1.Every piece is packed in particular Bubble Sheet after proper inspection for quality /defects of products
2.All pieces are packed in bubble sheets & parcel will be sent in plastic/ carton boxes.
Delivery Detail :3 days (Express Shipping).60 days (Economy Shipping)
DELIVERY DETAILS
We choose the best and safe packaging material to make sure your orders won’t be damaged during delivery.
1.Every piece is packed in particular Bubble Sheet after proper inspection for quality /defects of products
2.All pieces are packed in bubble sheets & parcel will be sent in plastic/ carton boxes.
Delivery Detail :3 days (Express Shipping).60 days (Economy Shipping)
DELIVERY DETAILS
We choose the best and safe packaging material to make sure your orders won’t be damaged during delivery.
