Quick Details
-
Model Number:
-
GW-15-D5-8-100
-
Dimension:
-
D395xH150mm
-
Storage:
-
None
-
SNR:
-
None
-
Output Power:
-
3200W Peak
-
Format:
-
None
-
Nominal diameter:
-
15inch
-
Nominal impedance:
-
8 Ohm
-
Nominal power handing:
-
800W
-
Sensitivity(1W/1m):
-
98 ± 2dB
-
Frequency Range(-10dB max):
-
42-2000 Hz
-
Voice Coil Diameter:
-
100mm
-
Voice coil material:
-
Inside/Outside 1 layer Cu
-
Magnet:
-
245*122*25(155OZ)
-
Basket:
-
Cast Aluminium
-
Keywords:
-
15 inch speaker woofer
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
OEM&ODM
-
Model Number:
-
GW-15-D5-8-100
-
Dimension:
-
D395xH150mm
-
Storage:
-
None
-
SNR:
-
None
-
Output Power:
-
3200W Peak
-
Format:
-
None
-
Nominal diameter:
-
15inch
-
Nominal impedance:
-
8 Ohm
-
Nominal power handing:
-
800W
-
Sensitivity(1W/1m):
-
98 ± 2dB
-
Frequency Range(-10dB max):
-
42-2000 Hz
-
Voice Coil Diameter:
-
100mm
-
Voice coil material:
-
Inside/Outside 1 layer Cu
-
Magnet:
-
245*122*25(155OZ)
-
Basket:
-
Cast Aluminium
-
Keywords:
-
15 inch speaker woofer
| Model Number | GW-15-D5-8-100 |
| Nominal diameter | 15inch |
| Nominal impedance | 8 ohm |
| DC resistance | 5.5 ohm |
| Nominal power handling | 800W |
| Continuous power handling | 1600W |
| Sensitivity(1W/1m) | 98 ± 2dB |
| Frequency range(-10dB max) | 42-2000 Hz |
| Voice coil diameter | 100mm |
| Voice coil material | Inside/Outside 1 layer Cu |
| Former material | BAF |
| Winding depth | 25mm |
| T yoke | 23mm |
| Plate | 12mm |
| Magnet | 245*122*25(155 oz) |
| Basket | Cast aluminum |
