- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
15 years warranty
-
Brand Name:
-
Bluesun, Bluesun
-
Model Number:
-
BSM440PMB7-46SC
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1812*1096*30mm
-
Product name:
-
solar panel 440W
-
Application:
-
Solar Power System
-
Packing Configuration:
-
36pcs/carton, 924pcs/40hq
-
Maximum system Voltage:
-
1500/1000V DC(IEC)
-
Junction Box:
-
IP68
-
Cable:
-
4.0mm2
-
Connector:
-
PV Compatible Connector
-
Keyword:
-
Solar Panel Pv Module
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, Bifacial, Double-glass, All Black, Mono
-
Panel Efficiency:
-
22.2%
-
Warranty:
-
15 years warranty
-
Brand Name:
-
Bluesun, Bluesun
-
Model Number:
-
BSM440PMB7-46SC
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1812*1096*30mm
-
Product name:
-
solar panel 440W
-
Application:
-
Solar Power System
-
Packing Configuration:
-
36pcs/carton, 924pcs/40hq
-
Maximum system Voltage:
-
1500/1000V DC(IEC)
-
Junction Box:
-
IP68
-
Cable:
-
4.0mm2
-
Connector:
-
PV Compatible Connector
-
Keyword:
-
Solar Panel Pv Module
Advantages Of Bluesun
Products Description
|
SPECIFICATIONS
|
|
|
|
|
|
|||||
|
Module Type
|
BSM420PMB7-46SC
|
BSM425PMB7-46SC
|
BSM430PMB7-46SC
|
BSM435PMB7-46SC
|
BSM440PMB7-46SC
|
|||||
|
|
STC
|
STC
|
STC
|
STC
|
STC
|
|||||
|
Maximum Power (Pmax/W)
|
420
|
425
|
430
|
435
|
440
|
|||||
|
Operating Voltage (Vmp/V)
|
34.5
|
34.6
|
34.7
|
34.8
|
34.9
|
|||||
|
Operating Current (Imp/A)
|
12.19
|
12.30
|
12.39
|
12.50
|
12.60
|
|||||
|
Open-Circuit Voltage (Voc/V)
|
41.6
|
41.7
|
46.8
|
46.9
|
47.0
|
|||||
|
Short-Circuit Current (Isc/A)
|
12.92
|
13.03
|
13.14
|
1326
|
13.37
|
|||||
|
Module Efficiency ηm(%)
|
21.1
|
21.4
|
21.7
|
21.9
|
22.2
|
|||||
|
STC: Irradiance 1000W/㎡ Cell Temperature 25°C・ Air Mass AM 1.5
|
|
|
|
|
|
|||||
|
|
|
|
|
|
||||||
Advantages Of Shingled Module
Compared with the normal module technology, the interconnected material of shingled module is different from that of normal module, whose technology is simpler and more reliable, avoiding the defects such as deviation of ribbon and cold soldering.
*Under the load of IEC 5400Pa, shingled has no new micro-cracks, although both shingled module and half-cell module passed the test(attenuation < 5%).
*High load resisting capacity reduces the production of micro-crack during transportation and power station installation.
