- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ZHENGKE
-
Model Number:
-
ZGB963FO
-
Torque:
-
15kgf.cm
-
Product Name:
-
Micro Brush DC Motor
-
Item name:
-
ZGB963FO
-
Keywords:
-
Brush Dc Worm Electric Motor
-
Size:
-
53mmX90mmX64mm
-
Feature:
-
Right Angle Gearbox
-
Input Voltage:
-
12v/24Vdc
-
Rated Speed:
-
16R,21R
-
Shaft:
-
Dia 8mm Shaft
-
Noise:
-
Under Db50
-
Certification:
-
ce
Quick Details
-
Speed(RPM):
-
21rpm
-
Continuous Current(A):
-
0.12A
-
Efficiency:
-
Ie 3
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ZHENGKE
-
Model Number:
-
ZGB963FO
-
Torque:
-
15kgf.cm
-
Product Name:
-
Micro Brush DC Motor
-
Item name:
-
ZGB963FO
-
Keywords:
-
Brush Dc Worm Electric Motor
-
Size:
-
53mmX90mmX64mm
-
Feature:
-
Right Angle Gearbox
-
Input Voltage:
-
12v/24Vdc
-
Rated Speed:
-
16R,21R
-
Shaft:
-
Dia 8mm Shaft
-
Noise:
-
Under Db50
-
Certification:
-
ce
|
MODEL
|
ZGB963FO
|
|
Material
|
METAL
|
|
Type Of Output Bearing
|
SLEEVE BEARING
|
|
Radial Force
|
≤ 3KGF
|
|
Axial Force
|
≤ 5KGF
|
|
Max Bearing Pressure Of Spindle
|
≤ 30KGF
|
|
Radial Clearance
|
≤0.1MM
|
|
Axial Clearance
|
≤0.5MM
|
Home&Office
---Electric Blinds, Automative Kitchen Cabinet, 3D Printer, Shredder, TV Lift, Table Lift, Smart Heating Control
System, Office Machine, Humidifier, BBQ. Pet Feeder
Security Industry
---Safebox, Smart Lock, Intellegent CCTV System, Access System Robot: Robot Arm, Robot Head, Education Robot,
Floor Cleaning Robot
Sanitary
---Tissue Dispenser, Towel Dispenser, Smart Toilet Seat, Air Freshener, Soap Dispenser
Others
---Valve, CNC Machine, Vending Machine, Camera Slipping, Medical Equipment.....
Carton Size: 36x32x38CM
Gross Weight: 19Kgs
