- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Household
-
Power Source:
-
Electric
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Jajalo
-
Model Number:
-
FC-C6
-
Power (W):
-
1500
-
Voltage (V):
-
220
-
Capacity:
-
8L/10L/15L/20L/30L
-
Color::
-
Silver/Gold/Blue
-
Style:
-
Vertical series
-
Body housing shell:
-
ABS
-
Rated Pressure(MPa)::
-
0.70mpa
-
Contorl::
-
Mechanical control
-
Water poof degree:
-
IPX4
-
Working indicator:
-
heating / off
-
Tank:
-
crystal enameled tank
-
Effluent mode::
-
Upper/lower
-
Warranty::
-
5 years
Quick Details
-
After-sales Service Provided:
-
None
-
Warranty:
-
1 Year
-
Installation:
-
Wall Mounted
-
Application:
-
Household
-
Power Source:
-
Electric
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Jajalo
-
Model Number:
-
FC-C6
-
Power (W):
-
1500
-
Voltage (V):
-
220
-
Capacity:
-
8L/10L/15L/20L/30L
-
Color::
-
Silver/Gold/Blue
-
Style:
-
Vertical series
-
Body housing shell:
-
ABS
-
Rated Pressure(MPa)::
-
0.70mpa
-
Contorl::
-
Mechanical control
-
Water poof degree:
-
IPX4
-
Working indicator:
-
heating / off
-
Tank:
-
crystal enameled tank
-
Effluent mode::
-
Upper/lower
-
Warranty::
-
5 years
Description of machine
1: 5 years quality warranty on tank.
2:ABS housing material with fashional and stylish design
3: 316L stainless steel heating element:Quality heating elements with seamless welding technology, achieves more effective prevention of crevice corrosion and long life,
4: Enameled inner tank: Electric water heater tank is a pressure vessel, with thickening of the high manganese steel materials, electrostatic dry powder enamel plasma welding process, anti-rust, corrosion, pressure.
5: Insulation: ultra-thick insulation and ultrafine microcellular foaming technology with CFC-free polyurethane foam ensures energy saving.
6: Multiple security protection: anti-dry heating protection, over pressure safety valve
7: Water heating and power off indicater
8: Cable line with ELCB: Quality cable.
9: Magnesium anode for purity
10: Enamel coating on water inlet / outlet
Technical Date-Overall Dimensions
|
Capacity |
10L |
15L |
20L |
30L |
|
H.S code. |
HS:851610 |
HS:851610 |
HS:851610 |
HS:851610 |
|
Tank |
crystal enameled tank |
crystal enameled tank |
crystal enameled tank |
crystal enameled tank |
|
Body housing shell |
ABS |
ABS |
ABS |
ABS |
|
Foam insulation |
polyurethane |
polyurethane |
polyurethane |
polyurethane |
|
Temperature control |
Mechanical |
Mechanical |
Mechanical |
Mechanical |
|
Working indicator |
heating / off |
heating / off |
heating / off |
heating / off |
|
Color |
Silver/Gold/Blue | Silver/Gold/Blue | Silver/Gold/Blue | Silver/Gold/Blue |
|
Rated Power Consumption ( W ) |
1000W/1500W |
1000W/1500W |
1000W/1500W |
1000W/1500W |
|
Power Supply ( V/Hz ) |
220-240V/50Hz |
220-240V/50Hz |
220-240V/50Hz |
220-240V/50Hz |
|
Rated Pressure ( MPa ) |
0.7mpa |
0.7mpa |
0.7mpa |
0.7mpa |
|
Temperature range ( ℃ ) |
( 35-75 ) ±5 |
( 35-75 ) ±5 |
(35-75)±5 |
( 35-75 ) ±5 |
|
Water-poof degree |
IP×4 |
IP×4 |
IP×4 |
IP×4 |
|
Net weight(kg) |
6.2KG |
7.6KG |
9.1KG |
11.80KG |
|
Gross weight(kg) |
7.9KG |
9.3KG |
11KG |
14.3KG |
|
packing |
Standard export carton |
Standard export carton |
Standard export carton |
Standard export carton |
|
product size
|
265×300×300 |
286X345X345 |
318X385X385 |
385X435X435 |
|
packing size(mm) |
350X350X350 |
410X415X325 |
450X450X355 |
505X510X415 |
|
Qty/40'FT |
1340 |
1020 |
780 |
535 |
|
Qty/40'HQ |
1560 |
1200 |
920 |
630 |
About US
FAQ
Q1:How long does the order take?
A:Sample order will be finished within 10 days and it will be delivered to customers about 5 days by DHL or FEDEX,while normal order will be finished within 20 days after receiving payment
Q2: How long is the warranty
A: We offer 5 years warranty for water tank, 1 year warranty for accessories.
Q3:Do you accept OEM or ODM orders?
A:Yes, Our R&D team will offer one stop service for you from original idea to finished product.
Q4:What’s the MOQ?
A: 500pcs(trial order's quantity is negotiable)
Q5: Do you provide samples? Is it free or extra?
A: Sample is available, sample fee will be returned when order is given
Q6: Can the price be cheaper?
A: Of course, you will be offered a good discount for big amount.
Q7: What payment terms?
A: T/T 30% deposit, balance paid before shipment.
