Quick Details
-
Place of Origin:
-
Fujian, China
-
Style:
-
Wireless
-
feature:
-
enlarge the distance
-
function:
-
suit for learning code rolling code optional
-
frequency:
-
customized
-
package:
-
standard corrugate case
-
normal frequency band:
-
433.92MHz (or customized)
-
Configuration Files:
-
superheterodyne reception
-
Modulation Model:
-
ASK
-
Receive sensitive:
-
-107dBm
-
Working temparature:
-
-25~55
Quick Details
-
Brand Name:
-
GIANT
-
Model Number:
-
JJ-JS-088
-
Type:
-
Wireless Repeater
-
Place of Origin:
-
Fujian, China
-
Style:
-
Wireless
-
feature:
-
enlarge the distance
-
function:
-
suit for learning code rolling code optional
-
frequency:
-
customized
-
package:
-
standard corrugate case
-
normal frequency band:
-
433.92MHz (or customized)
-
Configuration Files:
-
superheterodyne reception
-
Modulation Model:
-
ASK
-
Receive sensitive:
-
-107dBm
-
Working temparature:
-
-25~55
Wireless rf alarm 433mhz repeater
1.1 Operating Environment:
a) Working temperature: -25°C~+55°C
b) Storage temperature: -40°C~+85°C
c) Relative humidity: ≤95%
d) Atmosphere pressure: 86kPa~106kPa
2.2 Specifications
2.2.1 Frequency Band:
Normal frequency band: 433.92MHz (or customized)
2.2.2 Sensitivity
a) Normal sensitivity: 32±1dB
b) Sensitivity adjustable range: ≥25dB
2.2.3 Output Power
a) Normal output: 27±1dBm (27dBm=0.5W)
b) Output adjustable range: 10dBm~26dBm
2.2.4 Output resistance: 50Ω (disequilibrium)
2.2.5 Voltage standing wave ratio: ≤1.40
2.2.6 Transmitting distance: 500-1000 m
2.2.7 Sensitivity stability: ±1dB@-25°C~+55°C
2.2.8 Power stability: ±1dB@-25°C~+55°C
2.2.9 Configuration Files: superheterodyne reception
2.2.10 Modulation model: ASK
2.2.11 Receive sensitivity: ≤-107dBm
2.2.12 Quiescent Current: <200mA
2.2.13 Dynamic current: <1A
2.2.14 Working voltage: DC10.5V~18.5V
