Quick Details
-
Output Speed:
-
10-400RPM
-
Weight (KG):
-
2 KG
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Wuma or other
-
Ratio:
-
3-100
-
Label:
-
As required
-
Housing Material:
-
42CrMo
-
Input / Output shaft material:
-
40Cr
-
Machining precision of gears:
-
6 Grade
-
Warranty:
-
1 year after vessel date
-
Lubricating oil:
-
Synthetic Grease
-
Brand of bearings:
-
C&U,HRB
-
Vibration:
-
≤15μm
-
Quality Control System:
-
ISO9001:2008
Quick Details
-
Gearing Arrangement:
-
Planetary
-
Output Torque:
-
38-1080Nm
-
Input Speed:
-
6000rpm(max)
-
Output Speed:
-
10-400RPM
-
Weight (KG):
-
2 KG
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Wuma or other
-
Ratio:
-
3-100
-
Label:
-
As required
-
Housing Material:
-
42CrMo
-
Input / Output shaft material:
-
40Cr
-
Machining precision of gears:
-
6 Grade
-
Warranty:
-
1 year after vessel date
-
Lubricating oil:
-
Synthetic Grease
-
Brand of bearings:
-
C&U,HRB
-
Vibration:
-
≤15μm
-
Quality Control System:
-
ISO9001:2008
|
Efficiency |
0.98 |
|
Housing material |
42CrMo |
|
Gear material |
20CrMnTi |
|
Surface hardness of gears |
HRC58-62 |
|
Input / Output shaft material |
40Cr |
|
Machining precision of gears |
6 Grade |
|
Lubricating oil |
Synthetic Grease |
|
Heat treatment |
Carbonize&quencher |
|
Brand of bearings |
C&U,HRB |
|
Brand of oil seal |
SKF |
|
Noise (MAX) |
55-70 dB |
|
Temp. rise (MAX) |
70℃ |
|
Oil Temp. rise (MAX) |
40℃ |
|
Vibration |
≤15μm |
1. How to choose a gearbox which meets our requirement?
You can refer to our catalogue to choose the gearbox or we can help to choose when you provide
the technical information of required output torque, output speed and motor parameter etc.
2. What information shall we give before placing a purchase order?
a) Type of the gearbox, ratio, input and output type, input flange, mounting position, and motor information etc.
b) Housing color.
c) Purchase quantity.
d) Other special requirements.
3. What industries are your gearboxes being used?
Our gearboxes are widely used in the areas of textile, food processing, beverage, chemical industry,
escalator,automatic storage equipment, metallurgy, tabacco, environmental protection, logistics and etc.
4. Doyou sell motors?
We have stable motor suppliers who have been coperating with us for a long-time. They can provide motors
with high quality.
