^Voltage

^{DC12V(DC24V need order )}

^{Start Current}

^960mA

^{Standby Current}

^180mA

^{Solid Bolt}

^{polishing housing, 1000Kg Holding Force}

^{Suitable For}

^{Wooden Door, Glass Door, Metal Door, PVC Door}

^{Signal Output}

^{Door Status Output, NO/NC/COM}

^{Surface Temp}

^{Low Temperature}

^{Induction Distance}

^8mm

^{Operating temp}

^{-10~+55 degree (14-131F)}

^{Operating Humidity}

^{0~90%(non-condensing)}

^{Special Designed}

^{Tested to 500000 operations}

^{Face place material}

^{Stainless Steel}

^Weight

^0.676kg
