- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand:
-
Grandstream
-
Warranty:
-
1 Year
-
Product Dimensions:
-
22 * 13 * 4 inches
-
Item Dimensions L*W*H:
-
22 * 13 * 4 inches
-
Manufacturer:
-
GRANDSTREAM
-
Language:
-
English
-
Product Type:
-
Gateway
-
Color:
-
Gray
Quick Details
-
Type:
-
Gateway, Gateway
-
Brand Name:
-
Greadstream
-
Model Number:
-
GXW4108, GXW4108
-
Place of Origin:
-
Guangdong, China
-
Brand:
-
Grandstream
-
Warranty:
-
1 Year
-
Product Dimensions:
-
22 * 13 * 4 inches
-
Item Dimensions L*W*H:
-
22 * 13 * 4 inches
-
Manufacturer:
-
GRANDSTREAM
-
Language:
-
English
-
Product Type:
-
Gateway
-
Color:
-
Gray
Product Description
Grandstream GS-GXW4108 8 Port Fxo Gateway Overview
The GXW410x FXO gateway series enables businesses of all sizes to create and deploy a VoIP and analog hybrid solution. Make deployments easy by seamlessly connect multiple locations and all devices within an office to any hosted or on premise IP PBX network.
FEATURES
* Grandstream GXW FXO IP Analog Gateway with 4 ports
* Designed and tested for full interoperability with leading IP-PBXs, soft-switches and SIP-based environments
* Manageability, a simple configuration, superb voice and video quality and feature rich functionality
* Based on open industry standards
* Video surveillance port
* External power supply
* Two RJ-45 ports 10/100 Mbps (switched or routed)
* TFTP and HTTP firmware upgrade support
* Multiple SIP accounts (choice of 3 profiles per account)
* Programmable PSTN line settings for different countries/regions
* 1 or 2 stage dialing
* Caller ID
* G.168
* echo cancellation
* Flexible DTMF transmission: In Audio, RFC2833, SIP Info or any combination of the 3
* Selectable, multiple LBR coders per channel
* T.38 Fax compliant
* Designed and tested for full interoperability with leading IP-PBXs, soft-switches and SIP-based environments
* Manageability, a simple configuration, superb voice and video quality and feature rich functionality
* Based on open industry standards
* Video surveillance port
* External power supply
* Two RJ-45 ports 10/100 Mbps (switched or routed)
* TFTP and HTTP firmware upgrade support
* Multiple SIP accounts (choice of 3 profiles per account)
* Programmable PSTN line settings for different countries/regions
* 1 or 2 stage dialing
* Caller ID
* G.168
* echo cancellation
* Flexible DTMF transmission: In Audio, RFC2833, SIP Info or any combination of the 3
* Selectable, multiple LBR coders per channel
* T.38 Fax compliant
Product Details
|
Telephone Interfaces
|
GXW4108: 8 RJ11 FXO ports
|
|
Network Interfaces
|
10M/100Mbps, dual RJ45 ports
|
|
LED indicators
|
Power, Network and Line LEDs
|
|
Voice-over-Packet Capabilities
|
G.168 compiant Echo Cancelation, Dynamic Jitter Buffer, Moderm detection & auto-switch G.711
|
|
PTSN Fail-over Life Line
|
PTSN failover on power failure
|
|
Voice Compression
|
G.711, G.723, G.726 (40/32/24/16), G.729A/B/E, G.728, iLBC
|
|
DHCP Client
|
Yes, Switched Mode or PPPoE
|
|
Fax over IP
|
T.38 compliant Group 3 Fax Relay up to 14.4kpbs & auto-switch to G.711 for Fax Pass-through
|
|
QoS
|
Diffserve, TOS, 802.1P/Q VLAN tagging
|
|
IP Transport
|
RTP/RTCP
|
|
DTMF Method
|
flexible DTMF transmission method, user interface of in-audio, RFC2833, and/or SIP info
|
|
IP Signaling
|
SIP (RFC 3261)
|
|
SIP Server Profiles & Accounts Per System
|
Up to 2 distinct SIP server profiles per system and independent SIP account per port
|
|
Provisioning
|
TFTP and HTTP
|
|
Media
|
SRTP
|
|
Management
|
Syslog support, HTTPS, telnet, remote mamangement using web browser
|
|
Power
|
Output: 12VDC Input: 100-240VAC / 50-60Hz
|
|
Environmental
|
Operational: 32-104°F or 0-40°C
Storage: 14-140°F or -10-60°C
Humidity: 10-90% Non-condensing
|
|
Dimensions (LxWxH)
|
230mm x 135mm x 35mm
|
|
Mounting
|
Wall mount and desktop
|
|
Short & Long Haul
|
REN3: Up to 150ft on 24AWG line
|
|
Caller ID
|
Bellcore Type 1&2, ETSI, BT, NTT, and DTMF-based CID
|
|
Polarity Reversal/Wink
|
Yes
|
|
EMC
|
EN55022/EN5504 and FCC part 15 Class B
|
|
Safety
|
UL
|
