Quick Details
-
Brand Name:
-
Kaiyue
-
Place of Origin:
-
Hebei, China
-
Outlet Size:
-
50-300MM
-
Power:
-
0.55-800kw
-
motor:
-
three phase asynchronous Motor
-
Product name:
-
slurry pump
-
Color:
-
Silver
-
Certification:
-
ISO9001 CE
-
Brand:
-
Kaiyue
-
Package:
-
Wooden Case Package
-
Keywords:
-
slurry pump
-
Material:
-
cast iron
-
Usage:
-
mine
Quick Details
-
Application:
-
Drinking water treatment, Family Homes, Industrial Utilities, Irrigation and Agriculture, Washing and Cleaning, Wastewater Transport and Flood Control, wastewater treatment, Water Distribution, Water Treatment Solutions
-
Pressure:
-
Low Pressure
-
Voltage:
-
380v
-
Brand Name:
-
Kaiyue
-
Place of Origin:
-
Hebei, China
-
Outlet Size:
-
50-300MM
-
Power:
-
0.55-800kw
-
motor:
-
three phase asynchronous Motor
-
Product name:
-
slurry pump
-
Color:
-
Silver
-
Certification:
-
ISO9001 CE
-
Brand:
-
Kaiyue
-
Package:
-
Wooden Case Package
-
Keywords:
-
slurry pump
-
Material:
-
cast iron
-
Usage:
-
mine
Product Description
|
model
|
Flow(m³/h)
|
Lift(m)
|
Speed(r/min)
|
Power(kw)
|
|
300ZJ-I-A100
|
464-1826
|
15.3-65.2
|
300-590
|
450
|
|
300ZJ-I-A70
|
635-2333
|
16.0-76.8
|
490-980
|
630
|
|
250ZJ-I-A80
|
354-1416
|
26.7-114.0
|
490-980
|
710
|
|
250ZJ-I-A65
|
299-1249
|
15.4-71.0
|
490-980
|
318
|
|
200ZJ-I-A85
|
221-907
|
32.0-133.7
|
490-980
|
560
|
|
200ZJ-I-A60
|
218-870
|
13.9-62.0
|
490-980
|
185
|
|
150ZJ-I-A70
|
93-401
|
20.0-91.2
|
490-980
|
185
|
|
150ZJ-I-A50
|
115-460
|
9.5-43.1
|
490-980
|
75
|
|
100ZJ-I-A42
|
66-275
|
14.7-70.8
|
700-1480
|
90
|
|
100ZJ-I-A36
|
61-245
|
9.7-49.5
|
700-1480
|
55
|
|
80ZJ-I-A42
|
61-204
|
14.4-70.4
|
700-1480
|
75
|
|
80ZJ--I-A33
|
43-174
|
8.0-43.2
|
700-1480
|
37
|
|
65ZJ-I-A30
|
23-79
|
7.4-34.8
|
700-1480
|
15
|
|
50ZJ-I-A46
|
23-94
|
17.6-85.8
|
700-1480
|
55
|
|
40ZJ-I-A17
|
8-35
|
12.8-57.1
|
1430-2930
|
15
|
In stock
Certificate
Model Description Product Features Introduction to Scope of Application
This product has high efficiency, energy saving, long service life, light weight, reasonable structure, reliable operation and
convenient maintenance. It is suitable for electric power, metallurgy, coal, building materials and other industries. The
Bearing assembly: The bearing assembly of the pump adopts a cylindrical structure, which is convenient to adjust the gap between
the impeller and the front guard, and can be disassembled as a whole for maintenance. Bearings are grease lubricated.
Shaft seal (seal): The shaft seal types of the pump include packing seal, impeller seal and mechanical seal. The transmission
modes include V-shaped V-belt transmission, elastic coupling transmission, gear reduction box transmission, hydraulic coupling
transmission, variable frequency drive device, thyristor speed regulation, etc. Among them, the V-belt transmission includes CL,CV, CR, ZL, ZV, ZR transmission.
This product has high efficiency, energy saving, long service life, light weight, reasonable structure, reliable operation and
convenient maintenance. It is suitable for electric power, metallurgy, coal, building materials and other industries. The
processing medium is abrasive or corrosive slurry containing solid particles. The liquid mixing concentration mortar is 45%, the ore slurry is 60%, and the medium temperature is ≤60℃. This type of pump can be used in multi-stage cascade.
Pump body, pump cover and overflow parts This series of pumps are horizontal, vertical and middle type slurry pumps with doublepump casing structure. The pump body and pump cover are equipped with replaceable metal linings, which are made of high-chromiumwear-resistant alloy materials. The outlet direction of the pump can be rotated and installed at 8 angles.
Bearing assembly: The bearing assembly of the pump adopts a cylindrical structure, which is convenient to adjust the gap between
the impeller and the front guard, and can be disassembled as a whole for maintenance. Bearings are grease lubricated.
Shaft seal (seal): The shaft seal types of the pump include packing seal, impeller seal and mechanical seal. The transmission
modes include V-shaped V-belt transmission, elastic coupling transmission, gear reduction box transmission, hydraulic coupling
transmission, variable frequency drive device, thyristor speed regulation, etc. Among them, the V-belt transmission includes CL,CV, CR, ZL, ZV, ZR transmission.
Hebei Kaiyue Industrial Pump Manufacturing Co., Ltd. is a leading enterprise specializing in the production of industrial pump products. It is a professional pump production company integrating design, research and development. Strong capital strength and good corporate integrity are the guarantee for the company's development.
The company has strong strength, specializing in the research and development of high wear-resistant alloy materials, hired top domestic professional talents, and established long-term cooperative relations with relevant colleges and universities, so that the research and development of high wear-resistant alloy materials has hired domestic professional Top talents, and established long-term cooperative relations with relevant colleges and universities, making a breakthrough in the service life of high wear-resistant alloy materials.
The ZGB, ZJ, ZJL, ZGB series slurry pump products produced by our company have reached the domestic advanced level. Mining Company, Ningmei Group, Luneng Electric Power Company, Jinchuan Company, Jilin Metal Co., Ltd., Jinzhou Mining Company, Baiyin Co., Ltd. and other enterprises provide a large number of slurry pump products.
Production equipment
All products have been tested by professional institutions,
so that customers can buy more assured
Specification
|
item
|
value
|
|
Warranty
|
1years
|
|
Customized support
|
OEM, ODM, OBM
|
|
Brand Name
|
kaiyue
|
|
Model Number
|
zj
|
|
Place of Origin
|
China
|
|
|
Hebei
|
|
Application
|
Commercial Buildings, Irrigation and Agriculture, Marine, Metal and Equipment Manufacturers, Mining industry, Wastewater Transport and Flood Control, wastewater treatment
|
|
Power Source
|
Electric
|
|
Pressure
|
Low Pressure
|
|
Structure
|
Single-stage Pump
|
|
Outlet Size
|
40mm-350mm
|
|
Voltage
|
380v
|
|
Power
|
5.5kw-200kw
|
|
motor
|
Three-phase asynchronous motor
|
|
Product name
|
Slurry pump
|
|
Pump Type
|
Horizontal Pump
|
|
Application scope
|
Metallury
|
|
Motor power
|
2.2kw-250kw
|
|
Max Flow Rate
|
800m3/h
|
|
Function
|
Slurry Transmission
|
|
Outlet dia
|
40-350
|
|
Brand
|
kaiyue
|
|
Keywords
|
Slurry Pumps
|
|
Impeller
|
High Chrome
|
Packaging and Shipping
FAQ
Q:Are you a factory or trading company?
A: Our company is a professional manufacturer and trader that is concerned with the design,development
and production more than 20 years
Q:How can i get the quotation ?
A:Pls help to send the pump flow,head,power,caliber,voltage,frequency and quantity so that we could give you an accurate quotation
Q. What is your delivery time?
A: We have the stock with the sample order,7-15 days for container order. ( Busy season may need more days )
Q:What is your warranty ? What do we do in case of problems?
A:one year quality warranty is provided.In case of our quality problem, we will provide replacement by international courier.
Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material
ordering time which is normally 10-15 days
Q.How can we install the pump?
A:We have professional installation team and could provide one stop installation guide
Q:What is your payment terms?
A:Normally, 30% - 50% of total amount by T/T as deposit and balance before delivery. Irrevocable L/C at sight is also acceptable.
The sample order payment with Paypal,Western union are both ok.
Q: How to place order?
A:Send inquiry→Basic quotation→Confirm details→ PI & Contact→Pay deposit→Production (7-15 days)→Pay balance→Delivery (5-8 days by
air, 28-35 days by sea.) →After-sale service.
