- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
OEM
-
Raw material:
-
SiC
-
Color:
-
Black
-
Shape:
-
Customized
-
Heat resistance:
-
1600°C
-
Bulk density:
-
3.1g/cm3
-
Bending Strength:
-
>400Mpa
-
Thermal conductivity:
-
74w/(m.k)
-
Vickers Hardness HV:
-
22Gpa
-
Advantage:
-
Wear resistance
Quick Details
-
Material:
-
Silicon Carbide
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
HKCE-36
-
Brand Name:
-
OEM
-
Raw material:
-
SiC
-
Color:
-
Black
-
Shape:
-
Customized
-
Heat resistance:
-
1600°C
-
Bulk density:
-
3.1g/cm3
-
Bending Strength:
-
>400Mpa
-
Thermal conductivity:
-
74w/(m.k)
-
Vickers Hardness HV:
-
22Gpa
-
Advantage:
-
Wear resistance
Product Description
Introduction ：
High temperature resistance, high thermal conductivity, and atomization of oil and paste through electric heating on the base, providing customers with a pleasant user experience. The product is exported to Europe and America all year round, with mature production technology and has won the favor of many customers.
Feature：
Technical Data
碳化硅陶瓷
Technical Data of Silicon Carbide (SIC)
|
项目
Item |
单位
|
常压烧结碳化硅
SSIC |
反应烧结碳化硅
RBSIC/SISIC |
重结晶烧结碳化硅
RSIC |
|
|
UNIT
|
DATA
|
DATA
|
DATA
|
|
最高使用温度
Max temperature of Application |
℃
|
1600
|
1380
|
1650
|
|
密度
Density |
g/cm3
|
＞3.1
|
＞3.02
|
＞2.6
|
|
气孔性
Open Porosity |
%
|
＜0.1
|
＜0.1
|
15%
|
|
抗弯强度
Bending Strength |
Mpa
|
＞400
|
250(20℃)
|
90-100(20℃)
|
|
|
Mpa
|
|
280(1200℃)
|
100-120（1100℃)
|
|
弹性模量
Modulus of Elasticity |
Gpa
|
420
|
330(20℃)
|
240
|
|
|
Gpa
|
|
300（1200℃）
|
|
|
热传导系数
Thermal Conductivity |
W/m.k
|
74
|
45(1200℃)
|
24
|
|
热膨胀系数
Coefficient of Thermal Expansion |
K-1x10-6
|
4.1
|
4.5
|
4.8
|
|
维式硬度
Vickers Hardness HV |
Gpa
|
22
|
20
|
|
|
耐酸碱度
Acid Alkaline-proof |
|
优（excellent）
|
优（excellent）
|
优（excellent）
|
|
项目
Item |
单位
|
常压烧结碳化硅
SSIC |
反应烧结碳化硅
RBSIC/SISIC |
重结晶烧结碳化硅
RSIC |
|
|
UNIT
|
DATA
|
DATA
|
DATA
|
|
最高使用温度
Max temperature of Application |
℃
|
1600
|
1380
|
1650
|
|
密度
Density |
g/cm3
|
＞3.1
|
＞3.02
|
＞2.6
|
|
气孔性
Open Porosity |
%
|
＜0.1
|
＜0.1
|
15%
|
|
抗弯强度
Bending Strength |
Mpa
|
＞400
|
250(20℃)
|
90-100(20℃)
|
|
|
Mpa
|
|
280(1200℃)
|
100-120（1100℃)
|
|
弹性模量
Modulus of Elasticity |
Gpa
|
420
|
330(20℃)
|
240
|
|
|
Gpa
|
|
300（1200℃）
|
|
|
热传导系数
Thermal Conductivity |
W/m.k
|
74
|
45(1200℃)
|
24
|
|
热膨胀系数
Coefficient of Thermal Expansion |
K-1x10-6
|
4.1
|
4.5
|
4.8
|
|
维式硬度
Vickers Hardness HV |
Gpa
|
22
|
20
|
|
|
耐酸碱度
Acid Alkaline-proof |
|
优（excellent）
|
优（excellent）
|
优（excellent）
|
Our Company
Highborn Group is paying great attention to the product quality and technology research all the time. We have passed ROHS, CE,MSDS tests and also the ISO9001 authentication. We have 8 registered trademark and 25 patents. Also in 2020, we won the title of China High-tech Enterprise and Jiangsu Private Science and Technology Enterprises.
We can offer not only qualified products, we can also supplying quality service including design, development, export and after sales. With our professional skills, advanced technology and quality material, we can design and develop new products or new applications according to the clients’ expectation. We have custom-made new products and promoted the specifications for more than 1000 clients, and we have gotten good reputation from our clients.
Based on quartz and ceramics, after more than 20 years development, Highborn Group has grown up to a modern enterprise in research, manufacture, processing and sales. We are mainly supplying quartz glass, cuvette, precise ceramics, porous ceramics,thick film resistor, ozone generator, metal fiber felt and we have been offering our products and services to our clients from more than 112 countries or regions.
Honor Certificates
Our Service
Our mature and perfect production service system obtain customer satisfaction.
1. OEM Service.
2. More than 10 years-golden supplier of precise ceramic.
3. Professional package to ensure the transportation with no goods damaged.
4. Sampling Service.
5. Customized ceramics according to customer requirements and drawings, also design packaging and printing logo service.
6. After-sales service. Quick response, 100% feedback.
1. OEM Service.
2. More than 10 years-golden supplier of precise ceramic.
3. Professional package to ensure the transportation with no goods damaged.
4. Sampling Service.
5. Customized ceramics according to customer requirements and drawings, also design packaging and printing logo service.
6. After-sales service. Quick response, 100% feedback.
Packing and Delivery
Packaged by polybay and bubble bag in the stardard export carton,
Every package can be offered with English installation instruction.
We not only attach great importance to product quality, but also pay attention to constantly improve the customer service system.
FAQ
Answer: With the development more than 20 years, now we have 6 business division and we are supplying Quartz Glass (Tube, Rod, Plate and customized parts), optical glass and cuvette, and also various precise ceramics, porous ceramics and refractory ceramics. We have the full processing line for ceramic thick film resistors, far infrared ceramic glass heating panel, quartz tube/ceramic plate ozone generator and porous metal fiber felt. For all the products, we can design and customize according to the clients’ demand.
2: Before mass order, can you offer samples? How will you charge for them?
Answer: We are willing to offer samples to lower your purchasing risk. Generally, if from inventory, we can deliver out within 3days, however if need processing, we can deliver out within 15days. For some difficult items, the delivery time will be decided by its grade of difficulty. For some low value items, we can offer free sample, however we would like you to afford the freight cost. For customized products, we need to charge the developing cost.
3: What test report or certificate can you offer? What achievements have you made in research and development?
Answer: Till the end of 2021, we have passed many ROHS, CE, MSDS tests and also the ISO9001 authentication. We have 8 registered trademark and 25 patents. Also we won the title of China High-tech Enterprise and Jiangsu Private Science and Technology Enterprises.
4: Do you have any agent in our area? Can you export your products directly?
Answer: Till the end of 2021, we haven’t authorized any company or person as our regional agent. From 2008, we have the export qualification and professional export team, and till the end of 2021, we have exporting our products to more than 103 countries and regions, and our clients can contact us and purchase our products or service directly.
5: If the quality can not meet the requirement or any loss during the freight, how should we do?
Answer: We have strict QC test and professional QC team. We are always offering qualified products. If anything goes wrong, the quality can not meet requirement on the contract, we will reproduce the qualified products or refund the payment. We have the professional packing team and will pack the product in safe package for long distance delivery. If any loss during the freight, we hope you can assistant us to claim from the logistics company and we will arrange the replacement accordingly.
