Quick Details
-
Brand Name:
-
Longi solar
-
Model Number:
-
LR6-60PE-300M
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1650 x 991 x 40 mm
-
Weight:
-
18.5KG
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Power System
-
Cell Encapsulation:
-
EVA
-
Back Sheet:
-
Composite Film
-
Junction Box:
-
IP≥67, TUV
-
Cable:
-
Length 1000mm, 1x4mm
-
Connector:
-
MC4 Compatible Connector
-
Maximum system Voltage:
-
DC 1000V (IEC)
-
Certificate:
-
TUV/CE/IEC
Quick Details
-
Type:
-
PERC
-
Panel Efficiency:
-
18.3% - 19.6%
-
Warranty:
-
25 years linear output power warranty
-
Brand Name:
-
Longi solar
-
Model Number:
-
LR6-60PE-300M
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1650 x 991 x 40 mm
-
Weight:
-
18.5KG
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Power System
-
Cell Encapsulation:
-
EVA
-
Back Sheet:
-
Composite Film
-
Junction Box:
-
IP≥67, TUV
-
Cable:
-
Length 1000mm, 1x4mm
-
Connector:
-
MC4 Compatible Connector
-
Maximum system Voltage:
-
DC 1000V (IEC)
-
Certificate:
-
TUV/CE/IEC
Product Description
|
Typical Mechanical Characteristics
|
|
|
|
Dimension
|
1650 x 991 x 40 mm
|
|
|
Weight
|
18.5KG
|
|
|
Frame
|
Anodized Aluminum Profile
|
|
|
Front Glass
|
White Toughened Safety Glass, 3.2 mm
|
|
|
Cell Encapsulation
|
EVA
|
|
|
Back Sheet
|
Composite Film
|
|
|
Cells
|
6x10 Monocrystalline Solar Cells (5BB 156.75 x 156.75 mm)
|
|
|
Junction Box
|
IP ≥ 67, TUV&UL
|
|
|
Cable
|
Length 1000 mm, 1 x 4 mm²
|
|
|
Connector
|
Compatible with MC4
|
|
|
Packaging
|
|
System Design
|
|
||
|
Container 20'
|
360 pcs.
|
Temp. Range
|
-40℃ to +85℃
|
||
|
Container 40'
|
840pcs.
|
Hail
|
Max. diameter of 25mm with impact speed of 23m/s
|
||
|
Container 40'HC
|
910pcs.
|
Max. Capacity
|
Snow 5400 Pa, wind 2400 Pa
|
||
|
|
|
Application Class
|
A
|
||
|
|
|
Safety Class
|
Ⅱ
|
||
