High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape
High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape
High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape
High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape
High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape
High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape
High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape
High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape

High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape

FOB Reference Price: Get Latest Price
≥1000 Rolls
US $3.58
≥10000 Rolls
US $2.5
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Design Printing:
No printing
Material:
PVC Foam
Feature:
Waterproof
Place of Origin:
Zhejiang, China
Brand Name:
Hollyseal
Model Number:
P-350
Name:
PVC Foam Glazing Tape
Base material:
High Density PVC Foam
Glue:
Acrylic Pressure Adhesive
Density:
350±10kg/m3
Shore 00 Hardness:
80±10°
Flammability:
UL-94 V-0/HBF/HF-1/FMVSS 302
Release liner:
Blue Release Film
Core:
76mm Plastic/Paper Core
Tape thickness:
0.5-16mm
Port:
Shanghai/Ningbo

Quick Details

Adhesive:
Acrylic
Adhesive Side:
Double Sided
Adhesive Type:
Hot Melt, Pressure Sensitive, Water Activated
Design Printing:
No printing
Material:
PVC Foam
Feature:
Waterproof
Place of Origin:
Zhejiang, China
Brand Name:
Hollyseal
Model Number:
P-350
Name:
PVC Foam Glazing Tape
Base material:
High Density PVC Foam
Glue:
Acrylic Pressure Adhesive
Density:
350±10kg/m3
Shore 00 Hardness:
80±10°
Flammability:
UL-94 V-0/HBF/HF-1/FMVSS 302
Release liner:
Blue Release Film
Core:
76mm Plastic/Paper Core
Tape thickness:
0.5-16mm
Port:
Shanghai/Ningbo
PVC FOAM PRODUCTION INTRODUCTION


High Density PVC Foam Structural Glazing Tape Double-sided Foam Tape

Hollyseal®PVC Foam Glazing is a 350±50 kg/m 3 density PVC foam which is coated both sides with high tack acrylic adhesive with blue filmic liner for easy release. It has an closed cell structure to allow curing of structural silicones on all sides of the joint.It is usually used to create a seal between a double glazed unit and the frame on both windows and doors.

Density： 350±50 kg/m 3 ；Thickness：0.5-16mm
Product Features
1.High shore hardness giving guaranteed joint thickness

2.Close-cell foam-seal out moisture and dust

3.Excellent resistance to weathering,oxidation and ultraviolet light

4.Compatible with most silicone sealants

5.Good peel strength and initial adhesion

6.PVC foam glazing tape with a smooth surface finish

6.Superior stick capabilities to different surfaces such as:metal,plastic,paper,wooden and silicon
Technical Information
Density
350±50 kg/m 3
Shore 00 Hardness
80±10°
Tensile Strength
≥800kPa
Elongation
≥70%
Force to compree
≥50kPa
180°Peel Strength
0.82N/mm
30% Compression set
≤7%
Flammability
UL-94 HF-1/HBF
FMVSS 302
(V0 can be customized)
Product Application
1.Spacer for two- and four- sided structural glazing systems

2.Residential and Commercial window glazing

3.Metal, wood, vinyl sliding window system

4.Commercial refrigeration glazing

5.Vibration Dampening

6.HVAC system
