Quick Details
-
Brand Name:
-
HAIAO
-
Model Number:
-
HAIAO-GA012
-
Usage:
-
Farm gates accessories
-
Material:
-
Q235 steel ,High tensile steel
-
Surface:
-
Hot dip galvanized
-
Application:
-
For farm gates
-
QC:
-
ISO9001
-
Special need:
-
We can do special size under customer's request
-
Sample service:
-
Free sample sent
-
Main market:
-
New Zealand, Australia,England,America,EU Farm accessories market
Quick Details
-
Frame Material:
-
Metal
-
Feature:
-
Easily Assembled, ECO FRIENDLY, Renewable Sources, Rodent Proof, Rot Proof, Waterproof
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
HAIAO
-
Model Number:
-
HAIAO-GA012
-
Usage:
-
Farm gates accessories
-
Material:
-
Q235 steel ,High tensile steel
-
Surface:
-
Hot dip galvanized
-
Application:
-
For farm gates
-
QC:
-
ISO9001
-
Special need:
-
We can do special size under customer's request
-
Sample service:
-
Free sample sent
-
Main market:
-
New Zealand, Australia,England,America,EU Farm accessories market
Hot dip galvanized farm gate Latchs,gate gudgeons,farm gate hinges
1>Farm gate hinges welded on gate gudgeons
welded socket for gates or pipe framework as a hinge point.
| Product ID | Dimension a (mm) | Dimension b (mm) |
| Y2081 | 16 | 41 |
| Y2082 | 20 | 51 |
2>Farm gate hinges bolt on gate hinge
One or two-piece hinge allows replacement for commonly used farm gates
The two-piece design has the advantages of the original Greyson Gates one-piece design but is now much easier to fit.
| Product ID | Dimension a (mm) | Dimension b (mm) |
| Y2112 | 34 | 20 |
| Y2123 | 34 | 20 |
3>F arm gate hinges strap
Bolted to wooden gates as a hinge
Range of sizes to suit different gate lengths.
| Product ID | Dimension a (mm) | Dimension b (mm) | Dimension c (mm) |
| Y2133 | 150 | 16 | 30 |
| Y2134 | 225 | 16 | 40 |
| Y2135 | 300 | 16 | 40 |
| Y2136 | 300 | 20 | 50 |
| Y2137 | 375 | 20 | 50 |
| Y2138 | 450 | 20 | 50 |
| Y2139 | 600 | 20 |
50
|
Click for More Information!!!
4>Through Post Gudgeons
Hang any type of gate where the strength of the through post design is required
Long pin options will allow for gate security when required
Back nuts allow gate adjustment.
| Product ID | Dimension a (mm) | Dimension b (mm) | Dimension c (mm) |
| Y13 | 250 | 16 | 41 |
| Y14 | 275 | 20 | 51 |
| Y15 | 275 | 20 | 65 |
| Y17 | 350 | 20 | 65 |
| Y19 | 425 | 20 | 65 |
5>Lock Through Gudgeon
Often used as the top gudgeon when hanging gates for the additional strength provided by the locking shaft which resists any lateral force that may be applied to a gate
Can also be installed upside down to prevent gates being lifted from their hinges
Recommended for most farm gate installations
Long pin prevents gate lifting off.
| Product ID | Dimension a (mm) | Dimension b (mm) | Dimension c (mm) |
| Y2001 | 200 | 16 | 41 |
| Y2002 | 250 | 16 | 41 |
| Y2003 | 275 | 20 | 51 |
| Y2004 | 350 | 20 | 51 |
| Y2005 | 425 | 20 | 51 |
| Y2006 | 275 | 20 | 65 |
6>Square Shank Gudgeon
The square shank design secures the gudgeon in the post and helps resist gudgeon rotation
Provides the benefit of both the through post and drive gudgeon design.
Click for More Information!!!
| Product ID | Dimension a (mm) | Dimension b (mm) | Dimension c (mm) |
| Y2031 | 275 | 20 | 50 |
| Y2032 | 350 | 20 | 50 |
7>Drive Gudgeon
Driven into timber posts as a quick, easy alternative to screw or through post design
Barbed models are designed to secure the gudgeon permanently in the post
Most often used as the lower gudgeon.
| Product ID | Dimension a (mm) | Dimension b (mm) | Dimension c (mm) |
| Y2044 | 200 | 20 | 65 |
8>Screw Gudgeons
Screw Gudgeons used where the strength and security of the through post design is not required
Tapered thread tightens as gudgeon is screwed into the post
Long pin prevents gate lifting off
One piece gudgeon end reduces the possibility of corrosion.
| Product ID | Dimension a (mm) | Dimension b (mm) | Dimension c (mm) |
| Y2051 | 100 | 12 | 41 |
| Y2052 | 105 | 16 | 31 |
| Y2053 | 140 | 16 | 41 |
| Y2054 | 150 | 20 | 51 |
| Y2055 | 150 | 20 | 65 |
| Y2057 | 200 | 20 | 65 |
9>Concrete Post Gudgeon
One size designed to fit all common sizes of concrete strainer posts from 125mm to 200mm square.
| Product ID | Dimension a (mm) | Dimension b (mm) | Dimension c (mm) |
| Y2061 | 125/200 | 20 | |
| Y2071 | 125/200 | 50 |
Click for More Information!!!
Application of Farm Gate accessories
Click for More Information!!!
We are professional in manufacturing farm gate accessories!
Q:How do you ship farm gates accessories?
A:Usually by sea.
Q:What information should I provide,if I want a get a quotation?
A:The specification of farm gates accessories or the application of it.
Q:How many days will the samples be finished?
A:Generally,5days for samples made.
1.Provide free samples quickly.
2.We have a professional team to design suitable farm gates accessories for you.
3.With fastest speed of delivery.
4.High-quality after-sales services(such as quality,shipment,etc.)
