Quick Details
-
Design:
-
Raidal
-
Used for:
-
Tractor
-
LI/SS:
-
157 A8/B
-
Max Speed.:
-
50 KM/H
-
Max Load:
-
4125 KG
-
Infl Pressure:
-
160 Kpa
-
Standard Rim:
-
12.00
Quick Details
-
Place of Origin:
-
Shandong, China
-
size:
-
16.9-30 16.9-34 18.4-30 18.4-34
-
Brand:
-
Agromaster
-
Design:
-
Raidal
-
Used for:
-
Tractor
-
LI/SS:
-
157 A8/B
-
Max Speed.:
-
50 KM/H
-
Max Load:
-
4125 KG
-
Infl Pressure:
-
160 Kpa
-
Standard Rim:
-
12.00
About GULUN
1 . Product Range : AGR, IND,TBB, OTR,Forklift, T railer and Solid tires.
2. Market : one of the leading products in domestic market and in the America, Europe, Southeast Asia, Australia, Africa etc.
3 . Manufacture Equipments : imported from Japan, German, Italy, Holland and USA , which possess the leading level of the world.
4. Certificates : ISO9001 :2000 , CCC (China), DOT (USA), ECE (Europ) and etc.
1)Wider tread. to effectively decrease contact area pressure and benefit fo rhte crop root.
2)Groove dispersive stress design,to maketread more puncture.
3)Deeper tread pattern. to provide more powerful traction.
4)Wear resistant compound ,to prolong tireservice life.
5) Radial tire gives better riding comfort,long tread lift on the road and saves working hours.
| Size | Pattern | Rim |
Tread Depth
mm |
Overall Diamater
mm |
Section Width
mm |
Relevant Pressure
KPA |
Max Loading(40KM/H A8)
KG |
| 280/85R24 | R-1 | W10 | 41 | 1086 | 282 | 160 | 1215 |
| 320/85R24 | R-1 | W11 | 43.5 | 1145 | 310 | 160 | 1500 |
| 320/85R28 | R-1 | W11 | 42 | 1255 | 319 | 160 | 1600 |
| 340/85R24 | R-1 | W12 | 44 | 1188 | 343 | 160 | 1650 |
| 340/85R28 | R-1 | W12 | 44 | 1289 | 343 | 160 | 1750 |
| 380/85R24 | R-1 | W13 | 46 | 1256 | 380 | 160 | 1950 |
| 380/85R26 | R-1 | W13 | 46 | 1307 | 380 | 160 | 1750 |
| 380/85R28 | R-1 | W12/W13 | 45 | 1293 | 380 | 160 | 1750 |
| 420/85R28 | R-1 | W14L | 48 | 1443 | 438 | 160 | 2430 |
| 420/85R30 | R-1 | W14L | 48 | 1480 | 435 | 160 | 2500 |
| 420/85R34 | R-1 | W14L | 48 | 1575 | 430 | 160 | 2650 |
| 420/85R38 | R-1 | W14L | 46 | 1679 | 418 | 160 | 2800 |
| 460/85R30 | R-1 | W15L | 49 | 1543 | 465 | 160 | 2900 |
| 460/85R34 | R-1 | W15L | 49 | 1650 | 465 | 160 | 3075 |
| 460/85R38 | R-1 | W15L | 50 | 1756 | 476 | 160 | 3250 |
| 460/85R42 | R-1 | W15L | 50 | 1856 | 476 | 160 | 3350 |
| 520/85R38 | R-1 | W18L | 50 | 1841 | 527 | 160 | 3875 |
| 520/85R42 | R-1 | DW18L | 51 | 1945 | 515 | 160 | 4125 |
| 260/70R16 | R-1 | W8 | 36 | 770 | 258 | 160 | 825 |
| 260/70R20 | R-1 | W8 | 36 | 872 | 258 | 240 | 1150 |
| 300/70R20 | R-1 | W9 | 37 | 952 | 295 | 160 | 1400 |
| 360/70R24 | R-1 | W11 | 42 | 1152 | 357 | 160 | 1500 |
| 380/70R24 | R-1 | W12 | 46 | 1190 | 380 | 160 | 1650 |
| 420/70R24 | R-1 | W13 | 48 | 1248 | 418 | 160 | 1900 |
| 420/70R28 | R-1 | W13 | 47 | 1349 | 418 | 160 | 2060 |
| 480/70R28 | R-1 | W15L/DW15L | 49 | 1421 | 479 | 160 | 2500 |
| 520/70R38 | R-1 | W16L/DW16L | 50 | 1749 | 516 | 160 | 3350 |
| 580/70R38 | R-1 | W18L/DW18L | 50 | 1827 | 577 | 160 | 3875 |
| 480/65R28 | R-1 | W15L/DW15L | 48 | 1335 | 479 | 160 | 2240 |
| 540/65R28 | R-1 | W18L/DW18L | 48 | 1413 | 550 | 160 | 2650 |
| 540/65R30 | R-1 | W18L/DW18L | 48 | 1464 | 550 | 160 | 2725 |
| 480/80R42 | R-1 | ||||||
| 480/80R50 | R-1 | ||||||
| 710/70R42 | R-1 | ||||||
| 710/70R38 | 953 | ||||||
| 620/70R30 | R1-W | ||||||
| 650/70R42 | R1-W |
