Quick Details
-
BCD Curve:
-
C/D
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HOCH
-
Model Number:
-
wifi circuit breaker 2p
-
Rated Frequency (Hz):
-
50/60Hz
-
Number of Pole:
-
1234
-
Product name:
-
wifi circuit breaker
-
Rated current:
-
10-100A
-
Rated voltage:
-
110/220V
-
Rated frequency:
-
50/60 Hz
-
Number of poles:
-
1P,2P,3P,4P
-
Operating temperature:
-
-25 ° c ~ + 65 ° c
-
Nominal short-circuit breaking capacity:
-
nic = 6kA Ics = 6kA
-
Protection degree:
-
IP20
-
Poles Number:
-
2
-
Rated Frequency:
-
50/60hz
Quick Details
-
Breaking Capacity:
-
6Ka
-
Rated Voltage:
-
110/400
-
Rated Current:
-
10-100A
-
BCD Curve:
-
C/D
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HOCH
-
Model Number:
-
wifi circuit breaker 2p
-
Rated Frequency (Hz):
-
50/60Hz
-
Number of Pole:
-
1234
-
Product name:
-
wifi circuit breaker
-
Rated current:
-
10-100A
-
Rated voltage:
-
110/220V
-
Rated frequency:
-
50/60 Hz
-
Number of poles:
-
1P,2P,3P,4P
-
Operating temperature:
-
-25 ° c ~ + 65 ° c
-
Nominal short-circuit breaking capacity:
-
nic = 6kA Ics = 6kA
-
Protection degree:
-
IP20
-
Poles Number:
-
2
-
Rated Frequency:
-
50/60hz
Product Description
HOCH Shift the future.
Remote control your electricity at anytime from anywhere with Tuya/eWelink APP.
Smart Life(tuya) WIFI circuit breaker remote control overload short circuit protection compatiable with Amazon Alexa and Google home for Smart Home.
Warm Notice :
This product only support above input, down output. Please don't reverse, otherwise the handle can't push up Some
customers have a distribution box at home, the input line is below, and the output is above.
customers have a distribution box at home, the input line is below, and the output is above.
Details Images
Feature
①
Remote control without the limit of time and place.
② Schedule/Timer/loop timer.
③ Energy monitoring, set pow-er unit price, can calculate house device power consumption.
④ Overload and short circuit protection, over voltage and under voltage protection, over current and under current protection.
⑤ Preset pow-er/current/voltage threshold values by APP.
⑥ Once the real-time pow-er/current/voltage reaches the threshold values.
⑦ The connected electrical appliances will be automatically turned off.
② Schedule/Timer/loop timer.
③ Energy monitoring, set pow-er unit price, can calculate house device power consumption.
④ Overload and short circuit protection, over voltage and under voltage protection, over current and under current protection.
⑤ Preset pow-er/current/voltage threshold values by APP.
⑥ Once the real-time pow-er/current/voltage reaches the threshold values.
⑦ The connected electrical appliances will be automatically turned off.
⑧
Leakage current protection
Detailed description
Product parameter
|
Standard
|
GB10963.1 ; IEC60898-1
|
|
Poles
|
2P / 4P
|
|
Rated Voltage
|
AC 230V (1P/2P); AC 400V(3P/4P)
|
|
Rated Current
|
10A~125A
|
|
Rated Frequency
|
50/60 Hz
|
|
Frame Grade Rated Current
|
125 A
|
|
Rated Impact Withstand Voltage
|
10 KA
|
|
Rated Short Circuit Breaking Capacity
|
6 KV
|
|
Control
|
Remote Control by Mobile Phone APP
|
|
Connection
|
2.4 G WIFI
|
|
Mechanism Life
|
≥ 10000 times
|
|
Protection Level
|
IP 20
|
|
Ambient Teperature
|
- 25 ℃ ~ 65 ℃
|
Product display
Wiring diagram
Application and Use
WIFI intelligent recloser circuit breaker can be widely used in household, factories, sduent dormitroy,
farmland, muicipal works and can intelliently remote control water pump, water heater, underfloor heating equiement, etc.
farmland, muicipal works and can intelliently remote control water pump, water heater, underfloor heating equiement, etc.
Company Introduction
HOCH Group established in 1990 , located in Liushi, Wenzhou. Managing 7 companies. More than 300 specialized cooperation company, and 2000 staff. Specialize in low voltage products,like Mini Circuit Breaker,AC Connector. Our Vision : HOCH Shift the future.
Certifications
Packing & Delivery
For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.
