Quick Details
-
Marketing Type:
-
Hot selling
-
Core Components:
-
Laser source
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Maven
-
Dimension(L*W*H):
-
1080*710*1170mm
-
Weight (KG):
-
100 KG
-
Product name:
-
Laser rust removal
-
Wavelength:
-
1080+/-10 nm
-
Fiber length:
-
Standard 10m or specify
-
Max speed range:
-
1500-3000 mm/s
-
Focal length:
-
20-50mm
-
Advantage:
-
clean surface ,no damage basement
-
cleaning energy:
-
1.5mj-20mj
-
Turn on/off time:
-
20Us
-
Keywords:
-
laser cleaning machine
-
clean head support model:
-
5 Models
Quick Details
-
Power:
-
200W, 100W, 500W, 1500W, 1000W
-
Laser Type:
-
Fiber Laser
-
Laser Source Brand:
-
RAYCUS
-
Marketing Type:
-
Hot selling
-
Core Components:
-
Laser source
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Maven
-
Dimension(L*W*H):
-
1080*710*1170mm
-
Weight (KG):
-
100 KG
-
Product name:
-
Laser rust removal
-
Wavelength:
-
1080+/-10 nm
-
Fiber length:
-
Standard 10m or specify
-
Max speed range:
-
1500-3000 mm/s
-
Focal length:
-
20-50mm
-
Advantage:
-
clean surface ,no damage basement
-
cleaning energy:
-
1.5mj-20mj
-
Turn on/off time:
-
20Us
-
Keywords:
-
laser cleaning machine
-
clean head support model:
-
5 Models
Product Description
Specification
|
Max average power (W)
|
500
|
|
Output central wavelength (nm)
|
1064±5
|
|
Beam quality (M
2
)
|
≤62.5
|
|
Power adjustment range (%)
|
10-100
|
|
Output power stability (%)
|
≤5
|
|
Pulse repetition rate (Khz)
|
20-50
|
|
Pulse length (ns)
|
130-160
|
|
Max pulse energy (mJ)
|
25
|
|
Fiber length (m)
|
10
|
|
Laser safety classification
|
4
|
|
Cooling
|
Water cooling
|
|
Item
|
Surface
|
Focal length(mm)
|
Efficiency(mm²/s)
|
Base Material Damage
|
|
Cast Iron
|
Severe corrosion (0.08mm)
|
>35mm
|
3500
|
No
|
|
Carbon steel
|
Mild corrosion (0.05mm)
|
>40mm
|
3000
|
>35mm
|
|
Stainless steel
|
Oil, slight corrosion
|
>50mm
|
3200
|
>35mm
|
|
Mould steel gear
|
Mild oily with scrap iron
|
>45mm
|
4200
|
>35mm
|
|
Aluminum
|
Oxide / surface spotting
|
>35mm
|
3600
|
>35mm
|
|
Stoving varnish
|
White stoving
varnish(0.1mm)
|
>20mm
|
3500
|
>35mm
|
