Quick Details
-
Dimension(L*W*H):
-
1750X2600X1720mm
-
Weight:
-
480 KG
-
Features:
-
loader and backhoe
-
Tractor HP:
-
25-30HP
-
3-Point linkage:
-
Cat-1
-
Towable Backhoe for sale:
-
ANON Cheap mini skid steer loader attachment Towable Backhoe for sale
-
DIGGING DEPTH:
-
1750mm
-
Reach from center line of swing pivot:
-
2600mm
-
loading Height:
-
1720mm
-
Extend Height:
-
2870mm
-
Transport Overhang:
-
1080mm
-
Undercut:
-
720mm
-
Certification:
-
CE
Quick Details
-
Application:
-
tractor backhoe
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
ANON
-
Dimension(L*W*H):
-
1750X2600X1720mm
-
Weight:
-
480 KG
-
Features:
-
loader and backhoe
-
Tractor HP:
-
25-30HP
-
3-Point linkage:
-
Cat-1
-
Towable Backhoe for sale:
-
ANON Cheap mini skid steer loader attachment Towable Backhoe for sale
-
DIGGING DEPTH:
-
1750mm
-
Reach from center line of swing pivot:
-
2600mm
-
loading Height:
-
1720mm
-
Extend Height:
-
2870mm
-
Transport Overhang:
-
1080mm
-
Undercut:
-
720mm
-
Certification:
-
CE
ANON Cheap mini skid steer loader attachment 4x4 compact tractor with loader and backhoe Towable Backhoe for sale
ANON Cheap mini skid steer loader attachment 4x4 compact tractor with loader and backhoe Towable Backhoe for sale
ANON Cheap mini skid steer loader attachment 4x4 compact tractor with loader and backhoe Towable Backhoe for sale
1.It is used for ditching in farms and grazing lands,digging pool,cleaning waterways as well as assistant excavating work in construction and building roads.
2.Hydraulic transmission is used,Featured with compact structure, flexibility, convenient operation and quick mounting and dismounting.
3.It uses hydraulic oil commonly with tractor. The hydraulic elements are standardized, convenient for operation and service.
| Model | LW-6 | LW-7 | LW-8 | LW-9 |
| Tractor HP | 25-30HP | 30-45HP | 45-60HP | 60-80HP |
| 3-Point Linkage | Cat-1 | Cat-1&2 | ||
| Structure Weight | 480kgs | 500kgs | 580kgs | 620kgs |
| Digging Depth(Two foot flat bottom) | 1750mm | 1950mm | 2250mm | 2550mm |
| Reach from center line of Swing Pivot | 2600mm | 2900mm | 3200mm | 3600mm |
| Loading Height(bucket at 60 degree) | 1720mm | 1840mm | 1930mm | 2210mm |
| Transport Height(MAX) | 1840mm | 2060mm | 2130mm | 2480mm |
| Extend Height | 2870mm | 3110mm | 3240mm | 3590mm |
| Loading Reach(bucket at 60degree) | 950mm | 1180mm | 1140mm | 1360mm |
| Transport Overhang | 1080mm | 1110mm | 1220mm | 1270mm |
| Undercut | 730mm | 830mm | 470mm | 520mm |
| Bucket Rotation | 180degree | |||
| Stabilizer Spread(up position) | 1310mm | 1310mm | 1310mm | 1310mm |
| Stabilizer Spread(down position) | 2100mm | 2100mm | 2340mm | 2340mm |
| Swing Arc | 180 degree | |||
| Bucket Width | 300mm | 400mm | 450mm | 500mm |
| Bucket Cubage | 0.036 | 0.045 | 0.052 | 0.063 |
