Quick Details
-
Power:
-
145 /2000 Kw/rpm
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Yuchai
-
Maximum Digging Height:
-
2910mm, 4950mm
-
Maximum Digging Depth:
-
2050mm
-
Max Digging Radius:
-
3520mm
-
Rated Speed:
-
2000rpm
-
Weight:
-
3740kg
-
Rated power:
-
42hp / 2200rpm
-
Engine::
-
Kabota V2403
-
Standard bucket capacity:
-
0.12m3
-
Standard bucket width:
-
630mm
-
Walking Speed::
-
3.4/4.8km/h
-
Swing Speed Of Platform:
-
11~13 rpm
-
Auxiliary Flow:
-
44l/m
-
Boom swing angle (left/right):
-
80°/50°
-
Certification:
-
CE
Quick Details
-
Operating Weight:
-
3.5TON
-
Bucket capacity:
-
0.12 m3
-
Engine Brand:
-
imported
-
Power:
-
145 /2000 Kw/rpm
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Yuchai
-
Maximum Digging Height:
-
2910mm, 4950mm
-
Maximum Digging Depth:
-
2050mm
-
Max Digging Radius:
-
3520mm
-
Rated Speed:
-
2000rpm
-
Weight:
-
3740kg
-
Rated power:
-
42hp / 2200rpm
-
Engine::
-
Kabota V2403
-
Standard bucket capacity:
-
0.12m3
-
Standard bucket width:
-
630mm
-
Walking Speed::
-
3.4/4.8km/h
-
Swing Speed Of Platform:
-
11~13 rpm
-
Auxiliary Flow:
-
44l/m
-
Boom swing angle (left/right):
-
80°/50°
-
Certification:
-
CE
YUCHAI 3.5T Crawler Excavator Diesel Digger
Product Description
YC35-8 Mini Excavator
The Yuchai YC35-8 is a conventional tail excavator that is big on performance. Powered by a 45hp diesel engine with a Japanese KYB hydraulic system and weighing almost 4 tonne the YC35-8 is a powerful digger for it size. The A/C cabin and LCD display makes for an ultra comfortable operating environment while still being able to open up the front and side windows if required.
Parameters
| Weight | 3740kg |
| Rated power | 42hp / 2200rpm |
| Engine: | V2403 |
| Standard bucket capacity: | 0.12m3 |
| Standard bucket width | 630mm |
| Walking Speed: | 3.4/4.8km/h |
| Swing Speed Of Platform: | 11~13 rpm |
| Auxiliary Flow | 44l/m |
| Boom swing angle (left/right) | 80°/50° |
| A Overall Length (Transport Position) | 4950mm |
| B Overall Height (Transport Position) | 2470mm |
| C Width of Undercarriage | 1618mm |
| D Width of Track | 300mm |
| E Platform Turning Radius | 1515mm |
| F Length Of Track | 2100mm |
| G Sprocket Centres | 1620mm |
| H Ground Clearance | 267mm |
| I Boom Height (Transport Position) | 1698mm |
| J Width Of Platform | 1494mm |
| K Height of Engine Hood | mm |
| L Platform Ground Clearance | 570mm |
| A Maximum Digging Height | 5200mm |
| B Maximum Dumping Height | 3680mm |
| C Maximum Digging Depth | 3535mm |
| D Maximum Digging Radius | 5590mm |
| D1 Maximum Reach | 5520mm |
| E Maximum Height Digging Radius | 3265mm |
| F Minimum Turning Radius | 1990mm |
| G Maximum Depth for Bulldozing | 433mm |
| H Maximum Height for Bulldozing | 250mm |
| Maximum digging force | 22.19kN |
| Ground Pressure | |
| Gradeability |
