ACT lpg manual pump glp lpg transfer mini pump 12v lpg transfer pump for gas station

ACT lpg manual pump glp lpg transfer mini pump 12v lpg transfer pump for gas station

FOB Reference Price: Get Latest Price

≥1 Pieces

US $545

≥5 Pieces

US $530

≥10 Pieces

US $510

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Warranty:: 1 years

Brand Name:: ACT-YQB5-5

Model Number:: YQB

Place of Origin:: Sichuan, China

Horsepower:: 2hp

Cable Length:: 1inch

Outlet Size:: 380v/220v, 220V/380V

Power:: standard

motor:: 100% Copper Wire,explosion proof

Product name::: LPG transfer pump

Liquid::: LPG, DME, liquid ammonia and other volatile liquids

Certificate::: ISO9001

Feature::: horizontal, booster

Application scope 1::: fuel station

Application scope 2::: filling small cylinder

Transport media 1::: liquefied petroleum gas

Transport media 2::: propane, propylene

Transport media 3::: liquid ammonia

Transport media 4::: dimethyl ether, freon, etc.

Quick Details

Application:: Automotive Industry, Biofuel Industry, District Energy, Family Homes, Industrial Utilities, Irrigation and Agriculture, Metal and Equipment Manufacturers, Mining industry, fuel station, filling small cylinder

Pressure:: 0.5Mpa

Voltage:: 50hz/60hz

Warranty:: 1 years

Brand Name:: ACT-YQB5-5

Model Number:: YQB

Place of Origin:: Sichuan, China

Horsepower:: 2hp

Cable Length:: 1inch

Outlet Size:: 380v/220v, 220V/380V

Power:: standard

motor:: 100% Copper Wire,explosion proof

Product name::: LPG transfer pump

Liquid::: LPG, DME, liquid ammonia and other volatile liquids

Certificate::: ISO9001

Feature::: horizontal, booster

Application scope 1::: fuel station

Application scope 2::: filling small cylinder

Transport media 1::: liquefied petroleum gas

Transport media 2::: propane, propylene

Transport media 3::: liquid ammonia

Transport media 4::: dimethyl ether, freon, etc.

Products Description

ACT lpg manual pump glp lpg transfer mini pump 12v lpg transfer pump for gas station

Product Description:

1. Our company produces YQB series of liquefied petroleum gas is the oil pump, mainly used for transporting liquefied petroleum gas. Propylene.

2. A volatile liquid of similar properties, such as ammonia. Widely used in gas, petroleum, chemical, pharmaceutical, metallurgy and other fields .

3. The pump is a positive displacement vane pump. The structure is advanced, and the stator surface is formed by the Composite curves.

4. At both ends of the mechanical seal, the fixed with end use of the "O" type sealing ring, the rotation movement of the coordination.

5. The parts are all made of metal, which have the function of safe and reliable use.

Type	Speed n	Flow Q	Differentia l Pressure	Working Pressure	Motor Model	Power N	Inlet Port Inch	Outlet Port Inch	Tem Range ℃
YQB2-5	600r.p.m	2m ³ /h	0.5MPa	1.6MPa	YB90M-4	1.5KW	1	1	-40~40
YQB5-5	780r.p.m	5m ³ /h	0.5MPa	1.6MPa	YL100L1-6	2.2KW	1	1	-40~40
YQB10-5	600r.p.m	10m ³ /h	0.5MPa	1.6MPa	YB132S-4	5.5KW	2	2	-40~40
YQB15-5	780r.p.m	15m ³ /h	0.5MPa	1.6MPa	YB132S-4	5.5KW	2	2	-40~40
YQB25-5	600r.p.m	25m ³ /h	0.5MPa	1.6MPa	YB160M-4	11KW	3	3	-40~40
YQB35-5	780r.p.m	35m ³ /h	0.5MPa	1.6MPa	YB160M-4	11KW	3	3	-40~40
YQB50-5	780r.p.m	50m ³ /h	0.5MPa	2.0MPa	YB160L-4	15KW	4	4	-40~40

Working Principle:

The utility model is a volume type vane pump, which works by centrifugal sliding of the blade, and the flow rate is related to the rotation speed of the shaft.

The curved surface is made of the original composite curve, which is composed of a stator and a rotor, a baffle plate and a blade, and the ten sealing cavity is composed of a stator and a rotor.

The surface of the stator is a composite curve, when the rotor rotates, the volume of the inlet cavity increases gradually, and the negative pressure is formed,So as to suck oil into. When the rotor is rotated to a certain angle, the volume section is gradually reduced, thus the oil hydraulic pressure is reduced.

Between the oil suction chamber and the pressure oil chamber, an oil block is arranged between the oil suction cavity and the oil pressure cavity.

Blade by centrifugal force and two baffle structure Thus, the surface of the stator is tightly combined with the inner surface of the pump, so that the pump can work normally under the rated condition.

Cast iron pump casing

Mainly used to transport liquefied petroleum gas, propylene, liquid ammonia, or transport various volatile liquids and petroleum products with similar properties

Copper core motor

Only supporting all-copper motor, less heat generation, not using inferior motor to save cost

Chengdu ACT Technology Co.,LTD

Located in Chengdu city, Sichuan province, China. With eighteen years development, one of largest CNG LPG kits manufacturers in China, mainly specializing in R&D, manufacturing CNG/LPG conversion kits for vehicles.

Our products have passed by ISO9001, ISO16949 certification of production management ,and BV, CE, CNAS inspection and certification of quality .

ACT has powerful productivity, excellent equipment, advanced technology and perfect quality testing system, so ACT products have been exported to many countries. ACT is well acknowledged by customers and end users for its high qualified products and excellent services.

Until now, we have participated in well-known foreign exhibitions as scheduled. Such as SUFGAS in Russia , Peru FIGAS in Peru , ALTFUELS in Mexico etc . , we have sold our products more than 60 countries around the world already. We are committed to promoting our products to the world , leads green world , better environment !

Top SMD Equipment

By High Presicion Machine

OEM&ODM Customized Service

We could provide customized products and OEM&ODM technology service. ACT pressure reducers and injector rails are processed via high-precision CNC machines,electronic components of ECU Kits are imported from international famous brands,and manufactured by top level SMD equipments.

In addition, ACT can provide installation support for full cng/lpg kits,and technical support services-after sales.Welcome to visit us,and looking forward to cooperating with you sincerely .

Packing & Delivery

Packaging

A:Common Packing: Plastic bag + Label + Inner Box+Export Carton
B:Customized Packing: OEM Label, Inner Box,etc.

C: Package will be processed after all the tests finished.

Transportation

(1)By sea,by air,or by express(TNT,

Fedex,UPS,DHL,Aramex,EMS etc);

(2) We can provide freight services or deliver the goods to your designated forwarder. We will do best to save your freight !

(3)We support most inlan d port, such as Shanghai ,Guangdong ,Chongqing ，ningbo..

FAQ

Why choose us?.................................................................

1)Top Quality. Every product is made through strictly production process and quality testing, which has pass the test of BV,ISO, CE and GOST, and been accepted by clients spreading over 43 countries even including Italy and Poland.

2)2-year Warranty. All products enjoying 2 years free of equipment maintainence warranty.

3)Free Sample. If you order a set of products for testing, we will return the freight to you from your next normal order;if you order a component for testing, we will return the sample charge to you.

4)Cost Saving. We provide long-life, shock-resistant autogas equipment with excellent quality and better performance, resulting in cost saving.

5)Quick Delivery. We promise to ship your goods with 3 days after confirming your order, or we would like to return your payment if you asked.

Can your factory supply OEM serive?.........................................

Yes, we can. Send us the sample or the detailed speicifications of the products you want to clone →calculate the cost of opening model →start to produce the sample for testing →continue to produce according to your feedback.

What's your MOQ, payment terms?............................................

Our MOQ :1 piece for sample order,5 pieces for normal order.

Our payment terms: T/T, D/P, L/C, Paypal, Westernunion.
