Stone CNC Router Machine Mini Engraving Machine Milling Machine for Stone Marble Granite Tile Cnc Router China

Stone CNC Router Machine Mini Engraving Machine Milling Machine for Stone Marble Granite Tile Cnc Router China

FOB Reference Price: Get Latest Price

≥1 Sets

US $1860

≥30 Sets

US $1690

≥50 Sets

US $1490

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Positioning Accuracy (mm):: 0.05 mm

No. of Spindles:: Other

Travel (X Axis)(mm):: 600 mm

Travel (Y Axis)(mm):: 900 mm

Repeatability (X/Y/Z) (mm):: 0.05 mm

Spindle Motor Power(kW):: 2.2

Place of Origin:: China

Voltage:: 220V/380v

Dimension(L*W*H):: 1450*1000*2000mm

Weight (KG):: 300

Product name:: 6090 Cnc Router

Application:: Wood Stone PVC

After-sales Service Provided:: Online Technical Support

Keywords:: Wood Carving Cnc Machine

Function:: Cutting Engraving Carving Milling

Working area:: 600*900mm

Spindle:: 2.2kw Water-cooling Spindle

Control system:: NcStudio Control System

Transmission:: Taiwan TBI Ball Screw

Software:: Ucancam / ArtCam/TYPE3

Quick Details

Working Table Size(mm):: 600×900

Machine Type:: CNC Router

Range of Spindle Speed(r.p.m):: 0 - 24000 rpm

Positioning Accuracy (mm):: 0.05 mm

No. of Spindles:: Other

Travel (X Axis)(mm):: 600 mm

Travel (Y Axis)(mm):: 900 mm

Repeatability (X/Y/Z) (mm):: 0.05 mm

Spindle Motor Power(kW):: 2.2

Place of Origin:: China

Voltage:: 220V/380v

Dimension(L*W*H):: 1450*1000*2000mm

Weight (KG):: 300

Product name:: 6090 Cnc Router

Application:: Wood Stone PVC

After-sales Service Provided:: Online Technical Support

Keywords:: Wood Carving Cnc Machine

Function:: Cutting Engraving Carving Milling

Working area:: 600*900mm

Spindle:: 2.2kw Water-cooling Spindle

Control system:: NcStudio Control System

Transmission:: Taiwan TBI Ball Screw

Software:: Ucancam / ArtCam/TYPE3

Products Disply

600*900*120mm Router

Beautiful Design

Heavy Duty Bed Structure

High Quality Accessiories

Processable materials:

Soft-metal

Stone

Marble

Wood

PVC

etc.

600*900*120mm Router

Beautiful Design
Heavy Duty Bed Structure
High Quality Accessiories

Processable materials:
Wood
PVC
Acrylic

etc.

400*400*120mm Router

Beautiful Design
Heavy Duty Bed Structure
High Quality Accessiories

Processable materials:
Soft-metal
Stone
Marble
Wood
PVC
etc.

Model			6090 CNC Router
Voltage			220/380V 50HZ
Machine Structure			8mm thickness welded steel tube,cast iron vertical shafts and steel gantry
Working Area			*600900120mm (Z Axis can customise)*
Control System			WeiHong card System (Optional:RichAuto A11 DSP Controller）
Spindle Power			Water cool 2.2kw(Optional Water cool 3.2kw/3.7kw or Air cool 2.2/3.5KW）
Spindle Speed			0-24000rpm
Motor			Stepper Motor 450B
Driver			CWD860H
Driving method			X,Y axis by helical gear rack,Z axis by TBI ball screw
Invert			BSET
Guid Rail			TRV
Demension			*145010002000mm*
Weight			300kg
