Quick Details
-
Model Number:
-
CLS-102
-
Protection Level:
-
IP66
-
Operating Temperature:
-
-20~+70℃(With no icing)
-
Max. Current:
-
10A
-
Feature:
-
Water-proof and oil-proof construction
-
Operating Speed:
-
5mm-0.5m/s
-
Operating Frequency:
-
Electical: 30 operations/min
-
Contact Resistance:
-
25mΩ max.(initial value)
-
Insulation Resistance:
-
100mΩ min.(below 500VDC)
-
Vibration:
-
10~55Hz,1.5mm double amplitude
-
Ambient temperature:
-
Using: -20~+70℃ (With no icing)
-
Humidity:
-
<95% RH
-
Electrical Life:
-
500,000 operations above
-
Certification:
-
TUV, ISO9001, CCC, CE
Quick Details
-
Max. Voltage:
-
380VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CNTD
-
Model Number:
-
CLS-102
-
Protection Level:
-
IP66
-
Operating Temperature:
-
-20~+70℃(With no icing)
-
Max. Current:
-
10A
-
Feature:
-
Water-proof and oil-proof construction
-
Operating Speed:
-
5mm-0.5m/s
-
Operating Frequency:
-
Electical: 30 operations/min
-
Contact Resistance:
-
25mΩ max.(initial value)
-
Insulation Resistance:
-
100mΩ min.(below 500VDC)
-
Vibration:
-
10~55Hz,1.5mm double amplitude
-
Ambient temperature:
-
Using: -20~+70℃ (With no icing)
-
Humidity:
-
<95% RH
-
Electrical Life:
-
500,000 operations above
-
Certification:
-
TUV, ISO9001, CCC, CE
Features
Double circuit type of limit switch
Economic plastic type of limit switch
Small size, water-proof and oil-proof construction
Built-in contact box has double spring and long mechanical life
Smooth operation with larger over travel distance
Various actuators for different applications
Specifications
|
Operation speed
|
5mm-0.5m/s
|
|
|
|
|||
|
Operating frequency
|
Electical: 30 operations/min
|
|
|
|
|||
|
Contact rsistance
|
25mΩ max. (initial value)
|
|
|
|
|||
|
Insulation resistance
|
100mΩ min. (below 500VDC)
|
|
|
|
|||
|
|
1000VAC, 50/60 Hz for 1 minute between current-carrying and non-current-carrying metal parts
|
|
|
|
|||
|
|
1500VAC, 50/60 Hz for 1 minute between current-carrying and non-current-carrying metal parts
|
|
|
|
|||
|
|
1500VAC, 50/60 Hz for 1 minute between each terminal and ground
|
|
|
|
|||
|
Vibration
|
10~55Hz,1.5mm double amplitude
|
|
|
|
|||
|
Shock
|
Mechanical durable: 1,000m/Sec² (about 100G'S)
Malfunction: 300m/Sec² (about 30G'S)
|
|
|
|
|||
|
Ambient temperature
|
Using: -20~+70℃ (With no icing)
|
|
|
|
|||
|
Humidity
|
<95% RH
|
|
|
|
|||
|
Electrical life
|
500,000 operations above
|
|
|
|
|||
|
Protection level
|
IP66
|
|
|
|
|||
NOTES: The default size of conduit connector is M20x1.5, outfiting cable connector. Conduit connector size is PG13.5, with product model number plus (-P), example:CLS-103-P.
