Quick Details
-
Brand Name:
-
LUCKYSTAR
-
Model Number:
-
LS7D03-2201-2B
-
Color Temperature(CCT):
-
4000K, 4000K
-
Input Voltage(V):
-
AC220-240V,50/60Hz
-
Lamp Luminous Flux(lm):
-
2200
-
Working Temperature(℃):
-
-20 - 45
-
Cover Material:
-
pp
-
Base Material:
-
pp
-
PCs/ Ctn:
-
4
-
Packing Dimension:
-
/
-
Power brand:
-
LUCKYSTAR
-
Product Size:
-
420*420*28.5mm
-
Output voltage:
-
DC105-110V
-
Product power:
-
22W
-
Beam angle:
-
120°
-
Number of LEDs:
-
144PCS
-
LED type:
-
2835
-
Power factor:
-
>0.5
-
Waterproof Level:
-
IP20
Quick Details
-
Design Style:
-
Modern
-
Product Dimension:
-
/
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LUCKYSTAR
-
Model Number:
-
LS7D03-2201-2B
-
Color Temperature(CCT):
-
4000K, 4000K
-
Input Voltage(V):
-
AC220-240V,50/60Hz
-
Lamp Luminous Flux(lm):
-
2200
-
Working Temperature(℃):
-
-20 - 45
-
Cover Material:
-
pp
-
Base Material:
-
pp
-
PCs/ Ctn:
-
4
-
Packing Dimension:
-
/
-
Power brand:
-
LUCKYSTAR
-
Product Size:
-
420*420*28.5mm
-
Output voltage:
-
DC105-110V
-
Product power:
-
22W
-
Beam angle:
-
120°
-
Number of LEDs:
-
144PCS
-
LED type:
-
2835
-
Power factor:
-
>0.5
-
Waterproof Level:
-
IP20
| Product number |
LS7D03-2201-2B |
| Product Size | 420*420*28.5mm |
| Product material | PP+PS |
| Product power | 22W |
| Voltage | AC220-240V,50/60Hz |
| Output voltage | DC105-110V |
| Input Current | 0.1730A |
| Power type | Built-in, constant current |
| Color temperature | 4000K |
| luminance |
1800Lm |
| Beam angle | 120° |
| Number of LEDs | 144PCS |
| LED type | 2835 |
| Whether dimming | NO |
| Whether strobe or not | Yes |
| Mounting | Surface Mounted |
| Waterproof level | IP20 |
| Warranty | 2 years |
| Certification | GS / CE / ROHS |
Features
Use PP plastic frame to reduce product weight and reduce material cost
High brightness LED lamp beads, Ra>80, SDCM<6, no UV radiation
Monochrome, RGBW+IR, CCT+IR, segmented dimming, etc.
Nano light guide plate, uniform light output
Indoor use, protection class IP20
10,000 hours of light decay does not exceed 5%
Under normal use, the product life is over 20,000 hours
Beautiful appearance, easy installation, easy ceiling installation
Use ambient temperature -20 ° C ~ 45 ° C
Storage environment temperature -25 ° C ~ 85 ° C
Applications
Lighting applications in large public places such as hotels, conference rooms, factories or offices, schools, hospitals;
Indoor lighting for homes, homes, etc.
KTV, bar and other scenes, rendering atmosphere;
