Quick Details
-
Motor:
-
4kw Ac motor
-
Controller::
-
48v 400ah
-
Battery:
-
48V, 8V/150Ah, 6 PCS deep cycle
-
Color:
-
Otional
-
battery charge cycles:
-
more than 700 times
-
Brake:
-
Rear drum brake and pedal park brake
-
warranty:
-
Two years
-
Suspension:
-
Front Independent Suspension
Quick Details
-
Tire Size:
-
10 INCH
-
Dimension:
-
3350X1260X1750MM
-
Condition:
-
Brand new
-
Motor:
-
4kw Ac motor
-
Controller::
-
48v 400ah
-
Battery:
-
48V, 8V/150Ah, 6 PCS deep cycle
-
Color:
-
Otional
-
battery charge cycles:
-
more than 700 times
-
Brake:
-
Rear drum brake and pedal park brake
-
warranty:
-
Two years
-
Suspension:
-
Front Independent Suspension
|
BATTERY POWER |
GASOLINE POWER |
||
|
Model no.: |
JHGFU-EE4S |
Model no.: |
JHGFU-EG4S |
|
KEY COMPONENTS |
|||
|
Motor: |
3kw DC or 4kw AC
|
Engine: |
Stable 300cc GY6, Water cooled, 4 stroke, single cylinder |
|
Controller: |
Imported Curtis Controller, 275A-400A |
Horse power &Torque: |
23.12HP(17KW), 25N.m |
|
Battery: |
48v 150ah Six cells 8-volt deep cycle(Standard) |
Drive Train: |
Automatic, continuously variable transmission (CVT) |
|
Charger: |
100-240v intelligent pulse charge with the function to recover the battery |
Fuel |
12L |
|
BODY & CHASSIS |
|||
|
Frame: |
Welded high intense steel with double coating(galvanized frame is an option) |
||
|
Body&Roof: |
High compact PP plastic front and rear body cover, injected |
||
|
Windshield: |
Tempered glass( unfoldable), Organic glass(Foldable or unfuldable) |
||
|
Cushion& Backrest: |
Reborn sponge with artificial leather and plastic bottom cover |
||
|
Beverage holders: |
4 cups holders |
||
|
Color: |
Any color as requirements(we also accept custom colors) |
||
|
STEERING & SUSPENSION |
|||
|
Steering: |
Self-compensating rack and pinion |
||
|
Suspension: |
Lifted heavy duty leaf spring with dumper&spring absorber |
||
|
Brake System: |
Rear mechanical drum brake plus pedal park brake |
Front&rear hydraulic brake with hand park brake |
|
|
Accelerator: |
stepless speed change |
||
|
Transimission: |
Motor Shaft Direct Drive |
Shaft drive or chain drive |
|
|
Rear Axle: |
Differential model |
||
|
Gear Selection: |
F-N-R |
||
|
F&R tyre: |
205/50-10 on road tyre with free wheel hub cover |
||
|
Start way: |
Electric start with key |
||
|
PERFORMANCE |
|||
|
Passenger |
4 Person |
||
|
Range (loaded): |
More than 90kms |
More than 300kms for each full tank. |
|
|
Max.speed: |
25km/h(Adjustable) |
45km/h |
|
|
Max.climbing ability: |
30% |
40% |
|
|
Brake Distance: |
≤4M |
≤4M |
|
|
Curb weight: |
500kgs |
360kgs |
|
|
Max.loading : |
600kgs |
600kgs |
|
|
Charging time: |
8-10 hours |
|
|
|
Battery lifespan: |
More than 700times charge cycles (for standard battery) |
|
|
|
DIMENSIONS |
|||
|
Overall dimensions: |
3100*1200*1710mm |
||
|
Min ground clearance: |
127mm |
||
|
Wheelbase: |
2390mm |
||
|
F&R Tread: |
840mm/985mm |
||
|
Packing size: |
3100*1200*1050mm |
||
|
Packing: |
With irom Rack(Pack with roof ,seats,steering,,dissambled) |
||
|
Loading: |
4units /20ft container, 12units /40GP container, 18units / 40HQ container |
||
|
ELECTRIC SYSTEMS |
|||
|
Lights: |
Head lights, night lights,tail lights,brake nights,turnning lights, the lights powered for gas power model is one 12v 12 ah dry battery. |
||
|
Combination switch: |
Combination swith under the steering wheel with the switchs of head light,turnning lights and horn |
||
