Quick Details
-
Model Number:
-
AM-RS-04F
-
Warranty:
-
2 years, 2
-
Type:
-
auto light onoff control
-
Power:
-
Load 35W max
-
Sensing Range:
-
6-8m
-
Name:
-
Motion Sensor Lighting Switch
-
Input/Output Voltage:
-
185-265Vac
-
Rated Load:
-
35W Max
-
Sensor Mode:
-
on/off
-
Sensor Distance:
-
6-8m
-
Material:
-
Plastic
-
Delay time:
-
default 15sec
-
Load Type:
-
LED Lamps, energy saving lamps
-
Application:
-
Corridor, Stair, Hallway Lighting
Quick Details
-
Voltage:
-
185-265Vac
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Allmay
-
Model Number:
-
AM-RS-04F
-
Warranty:
-
2 years, 2
-
Type:
-
auto light onoff control
-
Power:
-
Load 35W max
-
Sensing Range:
-
6-8m
-
Name:
-
Motion Sensor Lighting Switch
-
Input/Output Voltage:
-
185-265Vac
-
Rated Load:
-
35W Max
-
Sensor Mode:
-
on/off
-
Sensor Distance:
-
6-8m
-
Material:
-
Plastic
-
Delay time:
-
default 15sec
-
Load Type:
-
LED Lamps, energy saving lamps
-
Application:
-
Corridor, Stair, Hallway Lighting
New Automatic AC220V 120V Human presence Microwave Motion detection light sensor switch with radar sensor
The 5.8GHz Microwave Radar Sensor Switch is designed for intelligent lighting control, offering a sophisticated solution for both indoor and outdoor lighting systems. Utilizing 5.8GHz microwave signals, this radar sensor detects motion within its surroundings, enabling automatic on/off control of lighting without the need for direct contact or visible light. It performs exceptionally well in various environments.
Product Features:
- High Sensitivity Detection: The 5.8GHz microwave radar sensor boasts exceptional motion detection capabilities, sensitively detecting even the slightest movements of individuals, vehicles, and other objects.
- Versatile Application: This sensor is suitable for a wide range of lighting scenarios, including residential, commercial, and industrial settings, providing intelligent lighting solutions for diverse needs.
- Automated Control: The sensor automatically triggers the activation and deactivation of lighting based on detected motion, enhancing energy efficiency and environmental comfort.
- Energy-Efficient and Eco-Friendly: With precise motion detection, the sensor prevents unnecessary energy consumption, delivering a more energy-efficient and environmentally friendly lighting control method.
- Adjustable Parameters: Users can fine-tune sensor parameters such as sensitivity and delay time to achieve optimal lighting control results based on specific requirements.
- Easy Installation: The sensor offers a straightforward installation process, typically allowing for direct replacement of existing switches or integration with current lighting systems.
- Multiple Application Scenarios: In addition to lighting control, the 5.8GHz microwave radar sensor can be employed in other fields such as security systems, intelligent access control, and more.
| Input Characteristics | |
| Model No. | AM-RS-G5835 |
| Mains voltage | 185-265V |
| Stand-by power | <0.5W |
| Load Rating | 35W |
| Sensor Data | |
| Sensor principle | HF Microwave |
| Operation Frequency | 5.8GHz |
| Transmission power | <0.2mW |
| Detection range: Max(diameter*H) | 8m*6m Radius |
| Detection angle | 16° ~360° |
| Hold time | 15+/-5s (can be customized) |
| Environment | |
| Operation Temperature(Ta) | -20~40°c |
| IP Rating | IP20 |
