Quick Details
-
Warranty:
-
Other
-
Model Number:
-
FEPM-540M/6A-B
-
Place of Origin:
-
China
-
Panel Dimensions:
-
2278*1134*30mm
-
Application:
-
Solar Power System
-
Solar cell:
-
PERC MONO crystalline(144pcs)
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Waterproof,3 diodes
-
Cable:
-
4.0mm2, or customized length
-
Glass:
-
2.0mm AR Coating semi-tempered glass,low iron
-
Material:
-
Monocrystalline Silicon Solar Cells
-
Number of Cells:
-
144 Cells Half Cell
-
Weight:
-
31kg
-
Certificate:
-
TUV/CE/IEC/ISO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial
-
Panel Efficiency:
-
20.9%-21.48%
-
Warranty:
-
Other
-
Model Number:
-
FEPM-540M/6A-B
-
Place of Origin:
-
China
-
Panel Dimensions:
-
2278*1134*30mm
-
Application:
-
Solar Power System
-
Solar cell:
-
PERC MONO crystalline(144pcs)
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Waterproof,3 diodes
-
Cable:
-
4.0mm2, or customized length
-
Glass:
-
2.0mm AR Coating semi-tempered glass,low iron
-
Material:
-
Monocrystalline Silicon Solar Cells
-
Number of Cells:
-
144 Cells Half Cell
-
Weight:
-
31kg
-
Certificate:
-
TUV/CE/IEC/ISO
Recommend Products
Our engineers have rich field experience of solar energy system installation from 1kW up to 30kW for off-grid, and 5kW up to MW for grid-connected or on-grid solar power system, solar farms. Please do chat with us for details, and we will provide point to point, tailor-made system package that based on your conditions and best suits your solar power needs.
Product Description
We employ advanced equipment and skilled labour, dedicated to stringent quality control, from feeding, soldering, electroluminescence (UL) test, lamination, framing to final inspection, fully automated with the highest manufacturing standards.
Details Images
Specification
Mechanical Specification
|
Model Number
|
FEPM-540M/6A-B
|
|
Place of Origin
|
China
|
|
Cell size
|
182mmx182mm
|
|
Type
|
PERC, Half Cell, Bifacial
|
|
Panel Dimensions
|
2278*1134*30mm
|
|
Panel Efficiency
|
20.9%-21.48%
|
|
Certificate
|
TUV/CE/IEC/ISO
|
|
Warranty
|
25 years
|
|
Frame
|
Anodized Aluminium Alloy
|
|
Weight
|
32kg
|
|
Junction Box
|
IP68 Waterproof, 3 diodes
|
|
Glass
|
2.0mm AR coating semi-tempered glass, low iron
|
|
Solar cell
|
Monocrystalline Silicon Cells
|
|
ELECTRICAL CHARACTERISTICS(STC*)
|
|
|
|
|
||||
|
Module Type
|
FEPM-540M/6A-B
|
FEPM-545M/6A-B
|
FEPM-550M/6A-B
|
FEPM-555M/6A-B
|
||||
|
|
Front STC
|
Front STC
|
Front STC
|
Front STC
|
||||
|
Maximun Power at STC(pmp)
|
540W
|
545W
|
550W
|
555W
|
||||
|
Open Circuit Voltage(Voc)
|
49.50V
|
49.60V
|
49.70V
|
49.80V
|
||||
|
Short Circuit Current(Isc)
|
13.81A
|
13.90A
|
14.00A
|
14.10A
|
||||
|
Maximum PowerVoltage(Vmp)
|
41.55V
|
41.80V
|
42.05V
|
42.31V
|
||||
|
Maximum Power Current (Imp)
|
13.00A
|
13.04A
|
13.08A
|
13.12A
|
||||
|
Module Efficiency at STC(nm)
|
20.90%
|
21.10%
|
21.29%
|
21.48%
|
||||
|
Power Tolerance
|
(0,+4.99)
|
|
|
|
||||
|
Maximum System Voltage
|
1500 Vdc
|
|
|
|
||||
|
Pmax Temperature Coefficient
|
-0.34%/°C
|
|
|
|
||||
|
Voc Temperature Coefficient
|
-0.26%/°C
|
|
|
|
||||
|
Isc Temperature Coefficient
|
+0.05%/°C
|
|
|
|
||||
|
Operating Temperature
|
-40~+85°C
|
|
|
|
||||
|
Nominal Operating Cell Temperature(NOCT)
|
45±2°C
|
|
|
|
||||
|
Module Type
|
FEPM-540M/6A-B
|
FEPM-545M/6A-B
|
FEPM-550M/6A-B
|
FEPM-555M/6A-B
|
|
|
Back STC
|
Back STC
|
Back STC
|
Back STC
|
|
Maximun Power at STC(pmp)
|
378W
|
382W
|
385W
|
389W
|
|
Open Circuit Voltage(Voc)
|
49.48V
|
49.58V
|
49.68V
|
49.78V
|
|
Short Circuit Current(Isc)
|
9.74A
|
9.80A
|
9.87A
|
9.94A
|
|
Maximum PowerVoltage(Vmp)
|
41.61V
|
41.86V
|
42.10V
|
42.34V
|
|
Maximum Power Current (Imp)
|
9.09A
|
9.13A
|
9.15A
|
9.19A
|
|
Module Efficiency at STC(nm)
|
20.90%
|
21.10%
|
21.29%
|
21.48%
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
|
Container
|
20'GP
|
40'HQ
|
|
Pieces per pallet
|
36
|
36
|
|
Pallets per container
|
4
|
20
|
|
Pieces per container
|
124
|
720
|
