Quick Details
-
Warranty:
-
12 months
-
Brand Name:
-
JOYROAD
-
Accuracy Distance:
-
1-50M
-
Power Consumption(W):
-
12W
-
Function:
-
FATIGUE CAMERA adas ANTI COLLISION
-
Certification:
-
CE FCC ROHS
-
GPS:
-
GPS+Beidou
-
Product type:
-
Mobile HD DVR
-
Storage Temperature:
-
RH <80%
-
SD Card:
-
Max 512G
-
Memory:
-
256G SD Support
-
Video:
-
4-CH H.264 720P
-
Operating voltage:
-
DC 9V~16V
-
Function 1:
-
Lane Change Warning
Quick Details
-
Car Fitment:
-
Lamborghini-Agricultural Crawler Dozer, Terex Lift Truck
-
Voltages:
-
9-36V
-
Frequency Band:
-
BAND 1/2/3/5/7/8/18/28/38/42
-
Warranty:
-
12 months
-
Brand Name:
-
JOYROAD
-
Accuracy Distance:
-
1-50M
-
Power Consumption(W):
-
12W
-
Function:
-
FATIGUE CAMERA adas ANTI COLLISION
-
Certification:
-
CE FCC ROHS
-
GPS:
-
GPS+Beidou
-
Product type:
-
Mobile HD DVR
-
Storage Temperature:
-
RH <80%
-
SD Card:
-
Max 512G
-
Memory:
-
256G SD Support
-
Video:
-
4-CH H.264 720P
-
Operating voltage:
-
DC 9V~16V
-
Function 1:
-
Lane Change Warning
Product composition
n Device: It includes baseband processor, RF processing unit, data memory, real-time clock, exterior camera module, interior infrared camera (max 2, supporting infrared and photosensitive), 4G data communication, RS232 / UART interface, turn signal, anti jitter power supply and other devices.
n GPS sensor, three axis G-sensor, gyroscope.
n Vehicle charging / battery power supply
• The specific hardware configuration parameters are as follows :
Product parameters
|
Chip |
MT8665 |
WiFi |
2.4G 802.11 b/g/n |
|
Memory |
16GB+2GB(compatible 8GB+1GB) |
LCD |
NONE |
|
Main camera |
Videos:1080P/25 Frame |
DMS Camera |
Videos:720P/25 Frame |
|
Photos:2M |
Photos:1.3M |
||
|
Environmental monitoring Camera |
Videos:720P/25 Frame |
Orher Camera (Time sharing multiplexing ) |
Videos:720P/30 Frame |
|
Photos:1280x720 |
Photos:1280x720 |
||
|
Sensor |
Built in 6-axis gyroscope |
FM |
None |
|
BT |
BT 4.0 2.4G |
GPS |
GPS+Beidou(Or GPS+Glonass) |
|
Battery |
None |
RF Frequency band |
GSM900/1800,WCDMA B1/8,TDD LTE B38/39/40/41(narrowband 100Mhz),FDD LTE B1/3/5/8,TD-SCDMA BA/F |
|
Working temperature |
-20℃—70℃ |
Memory card |
MicroSD class 10 or above(8-128G) |
|
Working voltage |
12V/24V |
Fixed mode |
1 ,Movable support and paste glass |
|
RS232/uart |
Support |
Speaker |
2W 4Ω |
Functions of Intelligent Driving DVR
n Driving Records
n Parking Record
n WIFI Hotpot
n ADAS (Advance Driving Assistant System)
n DMS (Anti Fatigue Driving System)
n Environmental monitoring in the carriage
n Remote upgrade (OTA)
n Customers’WeChat official account ,APP, Supervision Platform Implementation : Remote viewing , Track query , Remote live broadcasting , Collision alert,etc.
