- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
HCNHK
-
Model Number:
-
Micro SWITHCH
-
Max. Current:
-
3A
-
Operating Temperature:
-
-40oC~+80oC
-
Protection Level:
-
IP40
-
Switch electrical life:
-
150,000000 times
-
Switch operating force:
-
80±20 grams force
-
Switch size:
-
12.8x5.6mm
-
Rating:
-
AC 3A/1A 125V DC 30V 0.1A
-
Withstand voltage:
-
AC 500V for 1 minute
-
Insulation resistance:
-
100MΩMim. DC 125V
-
Contact resistance:
-
100MΩ
-
Working temperature:
-
-40oC~+80oC
-
Certification:
-
CE
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
250 volts
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HCNHK
-
Model Number:
-
Micro SWITHCH
-
Max. Current:
-
3A
-
Operating Temperature:
-
-40oC~+80oC
-
Protection Level:
-
IP40
-
Switch electrical life:
-
150,000000 times
-
Switch operating force:
-
80±20 grams force
-
Switch size:
-
12.8x5.6mm
-
Rating:
-
AC 3A/1A 125V DC 30V 0.1A
-
Withstand voltage:
-
AC 500V for 1 minute
-
Insulation resistance:
-
100MΩMim. DC 125V
-
Contact resistance:
-
100MΩ
-
Working temperature:
-
-40oC~+80oC
-
Certification:
-
CE
Product Description
|
item
|
value
|
|
Certification
|
CE
|
|
Place of Origin
|
China
|
|
|
Zhejiang
|
|
Brand Name
|
HCNHK
|
|
Model Number
|
MICRO SWITHCH
|
|
Highest Current
|
AC 3A 125V
|
|
Max. Voltage
|
250 volts
|
|
LED
|
No
|
|
switch Mechanical Life
|
100,000Times
|
|
switch Operating force
|
80±20 grams force
|
|
switch size
|
12.8x5.6mm
|
|
Rating
|
3A / 1A 125V AC
|
|
Operating Force
|
80±20g
|
|
Withatand Voltage
|
AC 500V 1 Minute
|
|
Insulation Resistance
|
100 MΩ Mim. 250V DC
|
|
Contact Resistance
|
100MΩ
|
|
Operating Temperature
|
-40oC ~ +80oC
|
|
Mechanical Life
|
100,000 Cycles
|
|
Electrical life
|
20,000 cycles
|
