Quick Details
-
Application:
-
Outdoor
-
Design Style:
-
Modern
-
Type:
-
ringlock scaffolding
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
YOUFA
-
Model Number:
-
48.3*3.25,48.3*2.75
-
Product name:
-
Ringlock scaffolding system
-
Material:
-
Q355,Q235,Q195
-
Surface treatment:
-
Hot Dip Galvanized,Painted
-
Size:
-
48.3*3.25*200/300/500/1000/1500 or according to customer
-
Certificate:
-
SGS,ISO
-
Packing:
-
Bundle
-
MOQ:
-
200PCS
-
Thickness:
-
3.25,3.0,2.75,2.5
-
Standard:
-
EN74/BS1139/AS1576
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Other
-
Project Solution Capability:
-
Others
-
Application:
-
Outdoor
-
Design Style:
-
Modern
-
Type:
-
ringlock scaffolding
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
YOUFA
-
Model Number:
-
48.3*3.25,48.3*2.75
-
Product name:
-
Ringlock scaffolding system
-
Material:
-
Q355,Q235,Q195
-
Surface treatment:
-
Hot Dip Galvanized,Painted
-
Size:
-
48.3*3.25*200/300/500/1000/1500 or according to customer
-
Certificate:
-
SGS,ISO
-
Packing:
-
Bundle
-
MOQ:
-
200PCS
-
Thickness:
-
3.25,3.0,2.75,2.5
-
Standard:
-
EN74/BS1139/AS1576
Product Description
Ringlock scaffolding system
High quality construction used ringlock scaffolding system steel scaffold for sale
High quality construction used ringlock scaffolding system steel scaffold for sale
High quality construction used ringlock scaffolding system steel scaffold for sale
Ringlock scaffold is a new type of scaffolding, also called chrysanthemum disc type scaffolding system, scaffold system, wheel scaffold system, fastener scaffold, layher frame (rhea, layer frame, frame, because the scaffolding is the basic principle of the German layher invention (real) company, has been in the industry known as the "real"). Scaffold for disc type is the bowl of the scaffold after the upgrading of products, the scaffolding socket for 133 mm diameter, 10 mm thick disk, disk in eight open hole,the phi 48 * 3.5 mm, Q345B steel pipe family member, poling is every 0.50 m on a certain length of steel tube welding on a disk,in this novel, beautiful disc connection bar, at the bottom of the belt connected sets.
Specification
|
Standard
|
|
|
|
Size (mm)
|
Weight per pcs
|
|
|
48.3*3.25*200
|
1.7kg/pc
|
|
|
48.3*3.25*500
|
3.4 kg/pc
|
|
|
48.3*3.25*1000
|
5.85 kg/pc
|
|
|
48.3*3.25*1500
|
8.3 kg/pc
|
|
|
48.3*3.25*2000
|
10.7 kg/pc
|
|
|
48.3*3.25*2500
|
13.5 kg/pc
|
|
|
48.3*3.25*3000
|
15.58 kg/pc
|
|
|
Ledger
|
|
|
|
Size (mm)
|
Weight per pcs
|
|
|
48.3*2.75*600
|
3.59
|
|
|
48.3*2.75*900
|
6.93
|
|
|
48.3*2.75*1200
|
10.26
|
|
|
48.3*2.75*1500
|
13.60
|
|
|
48.3*2.75*1800
|
3.94
|
|
|
48.3*2.75*2000
|
7.59
|
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
