Quick Details
-
Cutting Area:
-
3000*1500mm
-
Cutting Thickness:
-
0-20mm
-
Control Software:
-
Cypcut
-
Place of Origin:
-
China
-
Brand Name:
-
SUNBEARING
-
Weight (KG):
-
400 KG
-
Type:
-
Fiber Lasr Cutting
-
Fiber laser cutter power:
-
500W, 750W, 800W, 1000W, etc
-
Material:
-
Iron, aluminum, carbon steel, stainless steel, copper, hardware etc
-
Power:
-
1000w
-
Transmission System:
-
Gear + Rails
-
MOQ:
-
1
-
Machine Color:
-
Support custom made
-
Gross weight:
-
3500kg
-
Machine Warranty:
-
1 year
-
Service:
-
OEM Service
Quick Details
-
Laser Type:
-
Fiber Laser
-
Cutting Speed:
-
40m/min
-
Cooling Mode:
-
WATER COOLING
-
Cutting Area:
-
3000*1500mm
-
Cutting Thickness:
-
0-20mm
-
Control Software:
-
Cypcut
-
Place of Origin:
-
China
-
Brand Name:
-
SUNBEARING
-
Weight (KG):
-
400 KG
-
Type:
-
Fiber Lasr Cutting
-
Fiber laser cutter power:
-
500W, 750W, 800W, 1000W, etc
-
Material:
-
Iron, aluminum, carbon steel, stainless steel, copper, hardware etc
-
Power:
-
1000w
-
Transmission System:
-
Gear + Rails
-
MOQ:
-
1
-
Machine Color:
-
Support custom made
-
Gross weight:
-
3500kg
-
Machine Warranty:
-
1 year
-
Service:
-
OEM Service
Products Description
|
Mode
|
J-3015T-6BG-D160-3000W
|
|
|
|
|||
|
Working Area
|
3000mm*1500mm
|
|
|
|
|||
|
Laser Type
|
Fiber laser
|
|
|
|
|||
|
Power
|
MAX-3000W
|
|
|
|
|||
|
X-axis travel
|
1510mm
|
|
|
|
|||
|
Y-axis travel
|
3020mm
|
|
|
|
|||
|
Z-axis travel
|
180mm
|
|
|
|
|||
|
Max positioning speed of X-Y axis
|
50m/min
|
|
|
|
|||
|
Positioning accuracy
|
±0.03mm
|
|
|
|
|||
|
Repositioning accuracy
|
±0.03mm
|
|
|
|
|||
|
Max Cutting Speed
|
50m/min
|
|
|
|
|||
|
Cutting Thickness
|
0-10mm
|
|
|
|
|||
|
Cut pipe Diameter
|
Up to 160mm
|
|
|
|
|||
|
Voltage
|
380V/50Hz
|
|
|
|
|||
|
Auxiliary Gas
|
O2 or air
|
|
|
|
|||
|
Max carrying weight
|
600kg
|
|
|
|
|||
|
Overall Dimension
|
8000*3250*1800mm
|
|
|
|
|||
|
Total machine weight
|
4000kg
|
|
|
|
|||
|
No.
|
Name
|
Model J-3015T
|
|
|
||
|
1
|
Machine Bed
|
Steel plate welding， Annealing treatment
|
|
|
||
|
2
|
Dedusting device
|
Middle suction bed
|
|
|
||
|
3
|
Crossbeam
|
Alloy steel
|
|
|
||
|
4
|
Working table
|
Single table
|
|
|
||
|
5
|
Control system
|
CYPCUT-FS3000S
|
|
|
||
|
6
|
Electrical components
|
Schneider
|
|
|
||
|
7
|
Pneumatic Components
|
Taiwan AIRTAC，Japan SMC
|
|
|
||
|
8
|
Servo motor
|
Japan MITSUBISHI 1500*2 +1000W+ 400W with Brake
|
|
|
||
|
9
|
Reducer
|
France MOTOREDUCER
|
|
|
||
|
10
|
Rack and pinion
|
Germany LEITESEN
|
|
|
||
|
11
|
Guide rail
|
JAPAN SMAGIC
|
|
|
||
