Quick Details
-
Power:
-
customized
-
Place of Origin:
-
China
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
battery powered rubber heating pad
-
Application:
-
Industrial heating parts
-
Materrial:
-
Silicon rubber
-
Shape:
-
Square,strip etc.
-
Temperature Range:
-
-60~250C
-
Rated Voltage:
-
12-380V
-
Thickness:
-
1.5-4 mm
-
Power deviation:
-
±5%
-
Insulation resistance:
-
≥5 MΩ
-
Wire type:
-
Silicone Braided Wire
-
Certification:
-
CE Rohs
Quick Details
-
Type:
-
silicone rubber heater
-
Power Source:
-
Electric
-
Voltage:
-
240V
-
Power:
-
customized
-
Place of Origin:
-
China
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
battery powered rubber heating pad
-
Application:
-
Industrial heating parts
-
Materrial:
-
Silicon rubber
-
Shape:
-
Square,strip etc.
-
Temperature Range:
-
-60~250C
-
Rated Voltage:
-
12-380V
-
Thickness:
-
1.5-4 mm
-
Power deviation:
-
±5%
-
Insulation resistance:
-
≥5 MΩ
-
Wire type:
-
Silicone Braided Wire
-
Certification:
-
CE Rohs
battery powered rubber heating pad
Description
1.Silicone rubber drum heater make the liquid and concretion inside the barrel easy to be taken out.
If the adhesives,grease,mineral pitch,paint,paraffin and various resin materials need to be heated,
they can be heated through the barrel body and supplement heat to it.
2.This equipment is not affected by the season and it can be used through the year.
The surface of the heater is installed with sensors and the temperature is controlled through temperature controllers.
Application
1. Damp-proof specification:plate material on the end surface,it is easy to avoid the damp;
it cannot be used in the water or at locations of frost formation.
2. The material and form of the heated objects will be different and the temperature of the heater will
vary depending on the operating environment.
Technical data
| Model | heater for drum(200L) | heater for pail can(20L) | heater for ltto can(200L) |
| Dimensions | 250×1740 | 200×860 | 125×1740 |
| Electrical data | 220V 2000W | 240V 800W | 220V 1000W |
| Temperature Range | 30-150°C EGO | 30-150°C EGO | 30-150°C EGO |
| Weight | appr 0.5kg | appr 0.4kg | appr 0.4kg |
