Quick Details
-
Warranty:
-
5years
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM100M-36
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
670*768*30
-
Application:
-
balcony/light/motor home
-
Product name:
-
Sola Panel
-
Solar cell:
-
A-grade
-
Keyword:
-
Pv Module
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Rated
-
Glass:
-
3.2mm Tempered Low Iron
-
Cable:
-
4.0mm2
-
Connector:
-
pv Connector
-
OEM Order:
-
Acceptable
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, TOPCON
-
Panel Efficiency:
-
19.43%
-
Warranty:
-
5years
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM100M-36
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
670*768*30
-
Application:
-
balcony/light/motor home
-
Product name:
-
Sola Panel
-
Solar cell:
-
A-grade
-
Keyword:
-
Pv Module
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Rated
-
Glass:
-
3.2mm Tempered Low Iron
-
Cable:
-
4.0mm2
-
Connector:
-
pv Connector
-
OEM Order:
-
Acceptable
Product Description
|
ELECTRICAL SPECIFICATIONS
|
|
|
|
|||
|
Model Type
|
BSM90M-36
|
BSM95M-36
|
BSM100M-36
|
|||
|
Nominal Maximum Power(Pmax)
|
90w
|
95W
|
100W
|
|||
|
Optimum Operating Voltage(Vmp)
|
22.4V
|
22.4V
|
22.4V
|
|||
|
Optimum Operating Current (Imp)
|
4.02A
|
4.24A
|
4.46A
|
|||
|
Open Circuit Voltage(Voc)
|
26.88V
|
26.88V
|
26.88V
|
|||
|
Short Circuit Current(lsc)
|
4.19A
|
4.42A
|
4.65A
|
|||
|
Module Efficiency
|
17.49%
|
18.46%
|
19.43%
|
|||
|
Cell Efficiency
|
21.4%
|
22.2%
|
23.0%
|
|||
|
Power Tolerance
|
0 to+3%
|
0 to+3%
|
0 to+3%
|
|||
|
Maximum System Voltage
|
DC 1500V
|
DC 1500V
|
DC 1500V
|
|||
|
Operating Temperature
|
-40℃~+85℃
|
-40℃~+85℃
|
-40℃~+85℃
|
|||
|
Maximum Series Fuse Rating
|
10A
|
10A
|
10A
|
|||
|
Number of Bypass Diode
|
1
|
1
|
1
|
|||
Certifications
Packing & Delivery
Project
Small solar panels can be used to power a host of applications that require lowpower.
They are good for devices that do not consume too much energy.
They can be used to power pocket calculators, watches, flashlights, cameras,wearable devices and radios.
They can also power laptops and mobile phones in combination withbatteries. These solar panels can recharge batteries and ensure continuouspower supply.
