Product Description
Automatic flow table
Standard:
ASTM C230 BS 4551-1 EN 459-2 EN 1015-3 EN 13279-2
Describe:
It is used for determining the consistency of cement mortars. The motor operated models are driven by a motor speed reducer and the number of drops are shown on the counter, which stops automatically the machine at the end of the cycle. Supplied complete with flow mould and tamper.
ASTM C230 BS 4551-1 EN 459-2 EN 1015-3 EN 13279-2
Describe:
It is used for determining the consistency of cement mortars. The motor operated models are driven by a motor speed reducer and the number of drops are shown on the counter, which stops automatically the machine at the end of the cycle. Supplied complete with flow mould and tamper.
Specification
|
Weight of vibrating part
|
4.35±0.15 kg
|
|
Height of drop
|
10±0.1 mm
|
|
Vibrating frequency
|
1 HZ
|
|
Working cycle
|
25 S
|
|
Table diameter
|
300±1 mm
|
|
Flow mould dimension
|
100 mm base dia. x 70 mm
top dia. x 60 mm high |
|
Motor Power
|
220V, 50Hz
|
|
Dimension
|
400×400×690 mm
|
|
Net weight
|
25 kg
|
