Quick Details
-
Brand Name:
-
De Tai
-
Voltage:
-
customized
-
Dimension(L*W*H):
-
2800x1800x2080mm
-
Weight (KG):
-
3400
-
Power (kW):
-
4
-
Center height:
-
135mm
-
Two top center distance:
-
550mm
-
Grinding diameter range:
-
8-200mm
-
Grinding wheel size range:
-
400x(2050)x203mm
-
Grinding wheel linear speed:
-
S45m/s
-
Grinding wheel motor power:
-
4kW
-
Head frame motor power:
-
1kW
-
Max weight of workpiece:
-
s50kg
-
Longitudinal nvurnnt ofwurkbenuti:
-
720mm
-
Feed speed of grinding wheel frame:
-
0.01-6000mm/min
Quick Details
-
Wheel Size(mm):
-
400x(20~50)x203mm
-
Year:
-
/
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
De Tai
-
Voltage:
-
customized
-
Dimension(L*W*H):
-
2800x1800x2080mm
-
Weight (KG):
-
3400
-
Power (kW):
-
4
-
Center height:
-
135mm
-
Two top center distance:
-
550mm
-
Grinding diameter range:
-
8-200mm
-
Grinding wheel size range:
-
400x(2050)x203mm
-
Grinding wheel linear speed:
-
S45m/s
-
Grinding wheel motor power:
-
4kW
-
Head frame motor power:
-
1kW
-
Max weight of workpiece:
-
s50kg
-
Longitudinal nvurnnt ofwurkbenuti:
-
720mm
-
Feed speed of grinding wheel frame:
-
0.01-6000mm/min
Specification
|
item
|
value
|
|
Head frame dial speed
|
10-400r/min
|
|
Head frame Mohs taper
|
MT5
|
|
Tailstock sleewwe trarvel
|
50mm (30mm)
|
|
Tailstock Mohs taper
|
MT4
|
|
Working accuracy roundness
|
s1.5pm
|
|
Diameter consistency
|
s3um/315mm
|
|
Surface roughness
|
Ra0.1-0.4pm
|
|
X-axis repetitive positioning accuracy
|
≤1.5pm(50times)
|
|
Z-axis repetitive positoning accuracy
|
≤1.0pm(60times)
|
|
Machine weight
|
3400kg
|
|
mplementation of standards
|
GB/T4685-2007、Q/320281BGF01-2016
|
|
(LxWxH) Machine tool Overall dimension
|
2800x1800x2080mm
|
