- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
6470 x2640 x2850mm
-
Weight:
-
8250 KG
-
Key Selling Points:
-
HIGH QUALITY
-
Marketing Type:
-
New Product 2022
-
Structure weight:
-
8250KG
-
Min.Ground Clearance:
-
450mm
-
Max.Traction Force:
-
46.2KN
-
Troubleshooter size:
-
440 x1960mm
Quick Details
-
Use:
-
Forestry log skidder
-
Place of Origin:
-
China
-
Brand Name:
-
CP
-
Dimension(L*W*H):
-
6470 x2640 x2850mm
-
Weight:
-
8250 KG
-
Key Selling Points:
-
HIGH QUALITY
-
Marketing Type:
-
New Product 2022
-
Structure weight:
-
8250KG
-
Min.Ground Clearance:
-
450mm
-
Max.Traction Force:
-
46.2KN
-
Troubleshooter size:
-
440 x1960mm
Product Description
Specification
|
item
|
value
|
|
Condition
|
New
|
|
Applicable Industries
|
Farms, Construction works
|
|
Showroom Location
|
Germany, Brazil, Mexico, Russia, Morocco, Sri Lanka, Australia
|
|
Condition
|
New
|
|
Type
|
Log skidder
|
|
Use
|
Forestry log skidder
|
|
Place of Origin
|
China
|
|
Warranty
|
2 years
|
|
Key Selling Points
|
HIGH QUALITY
|
|
Marketing Type
|
New Product 2022
|
|
Warranty of core components
|
2 years
|
|
Model
|
|
J-65
|
J-80A
|
|||
|
Type
|
|
Crawler
|
Wheel
|
|||
|
Maximum aggregate capacity in winter(m3)
|
The big end of the log faces forward
|
6
|
4
|
|||
|
|
the small end of the log faces forward
|
8
|
6
|
|||
|
Overall dimensions( L x W x H ) mm
|
|
5500 x 2250 x 2600
|
6470 x 2640 x 2850
|
|||
|
Axle base mm
|
|
2040
|
2805
|
|||
|
Track Gauge mm
|
|
1480
|
|
|||
|
Tread mm
|
|
|
2026
|
|||
|
Min.Ground Clearance mm
|
|
510
|
450
|
|||
|
Structure weight (kg)
|
|
7500
|
8250
|
|||
|
Gradeability
|
|
25 degree
|
20 degree
|
|||
|
Speed Km/h
|
|
2.8 - 12.4
|
Forward Speed: 2.22-32.6
|
|||
|
|
|
|
Reverse Speed:
|
|||
|
Rated Traction Force KN
|
|
34
|
33
|
|||
|
Max.Traction Force KN
|
|
46
|
46.2
|
|||
|
Engine Specifications
|
|
|
|
|||
|
Model
|
|
LR4B5-19
|
LR6B3-22
|
|||
|
Type
|
|
Vertical put, Four-stroke, water-cooling,
spray directly combustion chamber |
|
|||
|
|
|
|
|
|||
|
Rated Power(km)/Rotation(r/min)
|
|
47.8/1900
|
73.5/2200
|
|||
|
Diesel Consumption(g/km/h)
|
|
≤245
|
≤245
|
|||
|
Work device
|
|
|
|
|||
|
Rope capacity of winch drum
|
|
40m/17mm(Cable diameter)
|
17
|
|||
|
Maximum winch force of winch KN
|
|
≥55.7
|
≥60
|
|||
|
Speed of winch drum
|
|
35
|
51-373
|
|||
|
Troubleshooter size (H x W) mm
|
|
830 x 2250
|
440 x 1960
|
|||
Packing & Delivery
Packaging Details:
Packing method:Nude package
40HQ: 2 pcs
or as customer's requirement
