H3C S1850v2 series Ethernet switch is a full Gigabit WEB management switch independently developed, designed and launched by Xinhua San Technologies Co., Ltd (hereinafter referred to as H3C), which is specially designed for the construction of high-performance network requirements. It provides a more comprehensive security access policy and stronger ease of use for network management and maintenance on the basis of high performance; and it can be widely used in the network construction scenarios of multiple industries, such as the government, small and medium-sized enterprises, general education and vocational education, security monitoring and hotels, and so on.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
H3C
-
Model Number:
-
S1850V2
-
Place of Origin:
-
China
-
Condition:
-
Origianl
-
Warranty:
-
3 Years
-
Uplink Ports:
-
1-4*1G SFP Port
-
packet forwarding ratio:
-
20-140Mpps
-
switching capacity:
-
336Gbps
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
336Gbps
-
Brand Name:
-
H3C
-
Model Number:
-
S1850V2
-
Place of Origin:
-
China
-
Condition:
-
Origianl
-
Warranty:
-
3 Years
-
Uplink Ports:
-
1-4*1G SFP Port
-
packet forwarding ratio:
-
20-140Mpps
-
switching capacity:
-
336Gbps
Product Description
|
Port
|
S1850v2-9P:8 10/100/1000Base-T electrical ports + 1 1000Base-X SFP optical port
S1850v2-10P:8 10/100/1000Base-T electrical ports +2 1000Base-X SFP optical ports
S1850v2-26P:24 10/100/1000Base-T electrical ports + 2 1000Base-X SFP optical ports S1850v2-28P:2410/100/1000Base-T electrical ports + 4 1000Base-X SFP optical ports S1850v2-52P:48 10/100/1000Base-T electrical ports + 4 1000Base-X SFP optical ports S1850v2-10P-PWR: 8 10/100/1000Base-T electrical ports + 2 1000Base-X SFP optical ports
S1850v2-26P-HPWR: 24 10/100/1000Base-T electrical ports + 2 1000Base-X SFP optical ports S1850v2-28P-HPWR:24 10/100/1000Base-T electrical ports + 4 1000Base-X SFP optical ports |
|
Packet forwarding rate
|
S1850v2-9P:30Mpps
S1850v2-10P:30Mpps
S1850v2-26P:78Mpps
S1850v2-28P:108Mpps
S1850v2-52P:140Mpps
S1850v2-10P-PWR:30Mpps
S1850v2-26P-HPWR:78Mpps
S1850v2-28P-HPWR:108Mpps
|
|
Switching capacity
|
336Gbps
|
|
PoE capacity
|
The models with PWR are supported, others are not supported
|
|
Electrical port properties
|
Supports half-duplex, full-duplex, and self-negotiation operating modes Support MDI/MDI-X
|
|
Ethernet Features
|
Flow Control (802.3x) Green Ethernet (EEE) Port Auto Power Saving Dynamic Link Aggregation (802.3ad)/ Static Port Aggregation
802.1p, 802.1Q Cable Diagnostics STP(802.1D)/ RSTP(802.1w)/ MSTP(802.1s) TC snooping BPDU protection / Root protection / Loopback protection / Protection against TC-BPDU attacks |
|
IPv4
|
ARP
DHCP Client |
|
multicast
|
Support IGMP V1/V2/V3 Snooping Supports fast leave mechanism
|
|
QoS
|
Support Diff-Serv QoS Support SP/WRR/SP+WRR Traffic Limiting 802.1p/DSCP priority mapping priority mapping
|
|
system management
|
Supports FTP, TFTP, Xmodem, SFTP file upload and download management. Support SNMP V1/V2c/V3 Support NTP clock Support system work
log Support cluster management |
* Product performance description
