- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
JIESUTE
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
JST250GY-5 I
-
Engine:
-
CB250D-G,SOHC, Air Cooling ,Four Stroke ,Electric Start
-
Max. power:
-
12/7000 Kw/r/min
-
Max. torque(N.m/rpm):
-
17.5N.m/5500r/min
-
Start mode:
-
Electrical
-
Tires:
-
Front 80/100-21 Rear 110/100-18
-
Battery:
-
12V 6AH
-
L*W*H:
-
2165*805*1225mm
-
SEAT HEIGHT:
-
920mm
-
Wheelbase:
-
1440mm
-
Curb WEIGHT:
-
110kgs
Quick Details
-
Displacement:
-
250-450cc
-
Max. Speed:
-
> 80km/h
-
Motor:
-
Brushed
-
Brand Name:
-
JIESUTE
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
JST250GY-5 I
-
Engine:
-
CB250D-G,SOHC, Air Cooling ,Four Stroke ,Electric Start
-
Max. power:
-
12/7000 Kw/r/min
-
Max. torque(N.m/rpm):
-
17.5N.m/5500r/min
-
Start mode:
-
Electrical
-
Tires:
-
Front 80/100-21 Rear 110/100-18
-
Battery:
-
12V 6AH
-
L*W*H:
-
2165*805*1225mm
-
SEAT HEIGHT:
-
920mm
-
Wheelbase:
-
1440mm
-
Curb WEIGHT:
-
110kgs
Product Paramenters
|
L*W*H
|
2165mm*802mm*1255mm
|
|
Battery
|
12V6AH
|
|
Max Power
|
12/7000kw/r/min
|
|
Max Torque
|
17.5/5500N.m/r/min
|
|
Engine
|
CB250D-G SOHC,Air Cooling,Four Stroke Electric Start
|
|
Curb Weight
|
110KGS
|
|
Bore×Stroke
|
65.6*62.2mm
|
|
Ground Clearance
|
300mm
|
|
Displacement
|
223cc
|
|
Compression Ratio
|
9.3:1-9.9:1
|
|
Seat Height
|
920mm
|
|
Lubrication Method
|
Force-Feed and Splash
|
|
Fuel Tank Capacity
|
7L
|
|
Wheel Base
|
1440mm
|
|
Clutch Mode
|
Mannual Wet Multi-Plate
|
|
Start Mode
|
Electrical
|
|
Frame
|
High Strength Steel Tube Frame
|
|
Muffler
|
Stainless Steel and Aluminum Alloy Muffler
|
|
Ignition mode
|
Electric ECU
|
|
Gearshift Mode
|
Constant Mesh,2 stage transmission,5 gearshift
|
|
Tire
|
Deep Tooth Tire,Front 80/100-21 Rear 110/100-18
|
|
Front Shocks
|
Invert One Way Damping Front Shock Absorber,Adjustable
|
|
Rear Shocks
|
Single Chamber, Outter Air-bag Shock Absorber,Upper and Lower Damping Adjustable
|
|
Front Disk Brake
|
Double Piston Pump Hydraulic Front Brake System,Handle Bar Adjustable
|
|
Rear Disk Brake
|
Double Piston Pump Hydraulic Rear Brake System
|
|
Rim
|
High Strength Aluminum Alloy Rim,CNC Drum Core,Front1.60*21 Rear 2.15*18
|
