Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
974*565*2mm
-
Panel Efficiency:
-
>18%
-
N.W.:
-
0.6Kgs
-
G.W.:
-
1.1kgs
-
Junction box:
-
IP65 Rated
-
Cell Type:
-
Monocrystalline 156*156mm
-
Cable:
-
0.6 meters
-
Connector:
-
MC4Plugs
-
OEM Order:
-
Acceptable
-
Size:
-
1180 (L) x540(W) mm
-
Certificate:
-
TUV/IEC61215/IEC61730/CE/ISO
Quick Details
-
Cell size:
-
182mmx182mm
-
Brand Name:
-
DOKIO
-
Model Number:
-
DFSP-100M*6
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
974*565*2mm
-
Panel Efficiency:
-
>18%
-
N.W.:
-
0.6Kgs
-
G.W.:
-
1.1kgs
-
Junction box:
-
IP65 Rated
-
Cell Type:
-
Monocrystalline 156*156mm
-
Cable:
-
0.6 meters
-
Connector:
-
MC4Plugs
-
OEM Order:
-
Acceptable
-
Size:
-
1180 (L) x540(W) mm
-
Certificate:
-
TUV/IEC61215/IEC61730/CE/ISO
Most of the panels are in stock in our Europe warehouse and American warehouse, we can ship them to you within 72 hours
after you confirm order !!!
FREE SHIPPING FROM EU/USA OVERSEAS WAREHOUSE.
SAMPLE IS ALLOWABLE, FAST DELIVERY WITHIN 3 DAYS.
SAMPLE IS ALLOWABLE, FAST DELIVERY WITHIN 3 DAYS.
Recommend Products
All of the following Item have in Stock, Can Click the Link to Purchase, More than 10pcs, Welcome to send me message for
Discount!!!
Product Description
Specification
|
Model Number
|
DFSP-100M
|
|
Rating power (Pm)
|
100w±3%
|
|
Cells
|
Mono Perc 182x91 mm
|
|
Number of cells
|
30 (3x10) series connected
|
|
Size
|
970(L) x565(W) x2(H)mm
|
|
N,W./G.W.
|
0.7kgs/1.5kgs
|
|
Typical application
|
12V DC
|
|
Maximum voltage
|
600V DC
|
|
Operating temperature
|
45°C
|
|
Hail diameter @ 80Km/h
|
Up to 25 mm
|
|
Continuous wind pressure
|
Up to 24 m/s
|
|
Efficiency of cell
|
≥22%
|
|
Rated current (Im)
|
5.56A
|
|
Rated voltage(Vm)
|
18V
|
|
Short circuit Current(Isc)
|
5.81A
|
|
Open circuit Voltage(Voc)
|
22.5V
|
