Quick Details
-
Machine Weight:
-
360 kg
-
Product name:
-
mini dumper T50FL
-
Engine:
-
212cc Petrol engine
-
Engine Options:
-
Ducar//Loncin/B&S/Honda/Kohler engine (EPA Available)
-
Transmission System:
-
Full hydraulic system
-
Drive Type:
-
Crawler
-
Gear Pump Brand:
-
Danfoss or Marzocchi
-
Tipping:
-
Hydraulic
-
Track Width:
-
180mm
-
Payload:
-
500KG
-
Max Travel Speed:
-
3.5 KM/H
Quick Details
-
Engine Brand:
-
Loncin/B&S/Honda/Kohler engine
-
Power:
-
Other
-
Place of Origin:
-
China
-
Machine Weight:
-
360 kg
-
Product name:
-
mini dumper T50FL
-
Engine:
-
212cc Petrol engine
-
Engine Options:
-
Ducar//Loncin/B&S/Honda/Kohler engine (EPA Available)
-
Transmission System:
-
Full hydraulic system
-
Drive Type:
-
Crawler
-
Gear Pump Brand:
-
Danfoss or Marzocchi
-
Tipping:
-
Hydraulic
-
Track Width:
-
180mm
-
Payload:
-
500KG
-
Max Travel Speed:
-
3.5 KM/H
|
Model
|
T50FL
|
Loding capacity
|
500kg
|
|
Engine
|
Petrol engine 7hp, recoil start
|
Traveling speed
|
0-3.5km/h
|
|
Displacement
|
212cc
|
Limited grade ability
|
20 degrees
|
|
Net power
|
4.1kw/3600rpm
|
Min. Ground clearance
|
100mm
|
|
Transmission
|
Fully hydraulic system
|
Min. Turning radius
|
850mm
|
|
Working pressure
|
16.5Mpa
|
Wheel base
|
525mm
|
|
Driven type
|
Track
|
Track base
|
345mm
|
|
Track width
|
180mm
|
Overall length
|
1715mm
|
|
Track roller
|
4 pcs
|
Overall width
|
730mm
|
|
Track tensioning
|
Yes
|
Overall height
|
1160mm
|
|
Hydraulic pump
|
Duplex gear pump
|
Gross weight
|
390kgs
|
|
Pump brand
|
Danfoss or Marzocchi
|
Packing method
|
Plywood case
|
|
Hydraulic motor
|
2 pcs
|
Package size
|
175*75*120cm
|
|
Oil Radiatior
|
Yes
|
20GP
|
9 pcs
|
|
Hydraulic oil tank
|
20.5L
|
40HQ
|
38 pcs
|
