Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
hik
-
Model Number:
-
DS-2CD2143G0-I DS-2CD2143G2-IU
-
Video Compression Format:
-
H265
-
Technology:
-
Infrared DS-2CD2143G2-IU
-
Lens:
-
2.8mm,4mm option
-
Resolution:
-
4MP 1/3" Progressive Scan CMOS
-
Alarm Action:
-
Email Photo
-
IR Distance(m):
-
30M
-
Power Supply(V):
-
DC 12V/ POE
-
Network Interface:
-
RJ-45 10/100Mb Ethernet Slot
-
Effective Pixels:
-
2560 *1440@30fps
-
Supported Mobile Systems:
-
iPhone OS, Android
-
Supported Operating Systems:
-
Windows 8, Windows XP
Quick Details
-
Special Features:
-
NIGHT VISION, Motion Detection, Vandal-proof, Waterproof / Weatherproof, Human Motion Tracking, Face detection, Temperature Measurement, Sound Detection, Finger recognition, People Counting, Two-way Audio, Face Recognition
-
Function:
-
Two-way Audio, Alarm I/O, Built-in Mic, NIGHT VISION, Waterproof / Weatherproof, Wide Angle, Vandal-proof
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
hik
-
Model Number:
-
DS-2CD2143G0-I DS-2CD2143G2-IU
-
Video Compression Format:
-
H265
-
Technology:
-
Infrared DS-2CD2143G2-IU
-
Lens:
-
2.8mm,4mm option
-
Resolution:
-
4MP 1/3" Progressive Scan CMOS
-
Alarm Action:
-
Email Photo
-
IR Distance(m):
-
30M
-
Power Supply(V):
-
DC 12V/ POE
-
Network Interface:
-
RJ-45 10/100Mb Ethernet Slot
-
Effective Pixels:
-
2560 *1440@30fps
-
Supported Mobile Systems:
-
iPhone OS, Android
-
Supported Operating Systems:
-
Windows 8, Windows XP
key features
HIK CCTV Camera
DS-2CD2143G0-I
• 1/3" Progressive Scan CMOS
• 2560 ×1440@30fps• 2.8/4/6/8mm fixed lens
• Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
• Three streams
• 120dB WDR
• 2 Behavior analyses, and face detection
• BLC/3D DNR/ROI
• IP67
• Built-in micro SD/SDHC/SDXC card slot, up to 128 GB
• 3-Axis adjustment
|
Camera
|
HIK CCTV Camera DS-2CD2143G0-I
DS-2CD2143G2-IU
|
|
Image Sensor:
|
1/3" Progressive Scan CMOS
|
|
Signal System:
|
PAL
|
|
Min. Illumination:
|
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
|
|
Shutter time:
|
1/3 s to 1/100,000 s
|
|
Slow shutter:
|
Support
|
|
Lens:
|
2.8 mm: horizontal FOV: 98°, vertical FOV: 55°, diagonal FOV: 114°
|
|
|
4 mm: horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 93°
|
|
|
6 mm: horizontal FOV: 48°, vertical FOV: 27°, diagonal FOV: 54°
|
|
|
8 mm: horizontal FOV: 37°, vertical FOV: 21°, diagonal FOV: 44°
|
|
Lens Mount:
|
M12
|
|
Adjustment Range:
|
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
|
|
Day& Night:
|
IR cut filter with auto switch
|
|
Wide Dynamic Range:
|
120 dB
|
|
Digital noise reduction:
|
3D DNR
|
|
Compression Standard
|
|
|
Video bit rate:
|
32Kbps~16Mbps
|
|
Audio Compression:
|
-S: G.711/G.722.1/G.726/MP2L2/PCM
|
|
Audio bit rate:
|
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
|
|
Triple Streams:
|
Yes
|
|
|
|
|
Max. Image Resolution:
|
2560 × 1440
|
|
Frame Rate:
|
50Hz:25fps (2560 × 1440, 2304 × 1296, 1920 × 1080)
|
|
|
60Hz: 30fps (2560 × 1440, 2304 × 1296, 1920 × 1080)
|
|
Sub Stream:
|
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
|
|
|
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
|
Third Stream:
|
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
|
|
|
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
|
|
Image Enhancement:
|
BLC/3D DNR
|
|
Image Settings:
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
|
|
Target Cropping:
|
No
|
|
ROI:
|
1 fixed region for main stream and sub-stream
|
|
Day/Night Switch:
|
Auto/Schedule/Triggered by alarm in (-S)
|
|
Network
|
|
|
Network Storage:
|
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
|
|
Alarm Trigger:
|
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
|
|
Protocols:
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
|
|
General Function:
|
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
|
|
|
mask, Watermark, IP address filtering
|
|
System Compatibility:
|
ON-VIF (Profile S, Profile G),ISAPI
|
|
Interface
|
|
|
Communication Interface:
|
1 RJ45 10M / 100M Ethernet interface
|
|
On-board storage:
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
|
Reset Button:
|
Yes
|
|
Audio
|
yes
|
|
Environment Noise Filtering:
|
Support
|
|
Audio Sampling Rate:
|
16kHz / 32kHz / 44.1kHz / 48kHz
|
|
Smart Feature-set
|
|
|
Behavior Analysis:
|
Line crossing detection, intrusion detection
|
|
Line Crossing Detection:
|
Cross a pre-defined virtual line
|
|
Intrusion Detection:
|
Enter and loiter in a pre-defined virtual region
|
|
Recognition:
|
Face Detection
|
|
General
|
|
|
Operating Conditions:
|
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
|
|
|
Humidity 95% or less (non-condensing)
|
|
Power Supply:
|
12 VDC ± 25%, PoE (802.3af Class3)
|
|
Power Consumption:
|
12 VDC ± 25%, 5W
|
|
|
PoE(802.3af, class 3), 6.5W
|
|
Weather Proof:
|
IP67
|
|
IR Range:
|
Up to 30m
|
|
Dimensions:
|
Camera: Φ 111 × 82.4 mm (Φ 4.4″ × 3.2″)
|
|
|
Package: 134 × 134 × 108 mm (5.27″ × 5.27″ × 4.25″)
|
|
Weight:
|
Camera: 500 g (1.1 lb.)
DS-2CD2143G0-I
|
