Quick Details
-
Number of Row:
-
Single row
-
Model Number:
-
GW Type
-
Seals Type:
-
Sealed
-
Place of Origin:
-
Jiangsu, China, Jiangsu, China
-
Application:
-
lawn mowers, combines
-
Outer Ring Material:
-
Gcr15
-
Cage Material:
-
Steel
-
Ball Material:
-
Gcr15
-
Weight:
-
1.75 lbs
Quick Details
-
Applicable Industries:
-
Hotels, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Restaurant, Home Use, Retail, Food Shop, Energy & Mining, Other
-
Bore Size:
-
33 - 63 mm, 10-100mm
-
Precision Rating:
-
P0 P4 P5 P6
-
Number of Row:
-
Single row
-
Model Number:
-
GW Type
-
Seals Type:
-
Sealed
-
Place of Origin:
-
Jiangsu, China, Jiangsu, China
-
Application:
-
lawn mowers, combines
-
Outer Ring Material:
-
Gcr15
-
Cage Material:
-
Steel
-
Ball Material:
-
Gcr15
-
Weight:
-
1.75 lbs
Products Description
Introduction to products:
1. Bearing material: using excellent bearing steel, long service time, high precision.
2. Bearing performance: low friction, high speed and not easy to burn, high load resistance.
3. Bearing quality: good quality, avoid repeated disassembly and maintenance trouble.
4. Good speed: the running speed is uniform, and the machine works in coordination to improve efficiency.
Agricultural machinery bearing is an important basic component of agricultural machinery equipment, widely used in agricultural vehicles, tractors, diesel engines, motors, rake, baling machine, harvester, thresher and other agricultural machinery, its accuracy, performance, the accuracy of the host, the performance plays a decisive role.
Details Images
|
Bearing Number
|
Bore Type
|
Bore Diameter
|
Outside Diameter
|
Inner Width
|
Outer Width
|
Weight
|
|||
|
|
|
mm
|
|
|
|
Kg
|
|||
|
GW208PPB6
|
Square
|
25.4
|
80
|
36.53
|
21
|
0.794
|
|||
|
GW208PPB5
|
Square
|
28.6
|
80
|
36.53
|
21
|
0.667
|
|||
|
GW208PPB8
|
Square
|
28.6
|
80
|
36.53
|
30.18
|
0.794
|
|||
|
GW208PPB17
|
Square
|
28.6
|
80
|
36.53
|
30.18
|
0.925
|
|||
|
GW209PPB5
|
Square
|
31.8
|
85
|
36.53
|
30.18
|
0.794
|
|||
|
GW209PPB8
|
Square
|
31.8
|
85
|
36.53
|
22
|
0.748
|
|||
|
GW210PP4
|
Square
|
28.6
|
90
|
30.18
|
30.18
|
1.048
|
|||
|
GW210PPB4
|
Square
|
28.6
|
90
|
30.18
|
30.18
|
0.794
|
|||
|
GW211PP3
|
Square
|
38.1
|
100
|
33.34
|
33.34
|
1.266
|
|||
|
GW211PPB3
|
Square
|
38.1
|
100
|
33.34
|
33.34
|
1.207
|
|||
|
GW211PP17
|
Square
|
38.1
|
100
|
44.45
|
33.34
|
1.188
|
|||
|
GW214PPB4
|
Square
|
50.8
|
125
|
39.69
|
39.69
|
2.155
|
|||
|
GW216PPB4
|
Square
|
44.4
|
140
|
63.5
|
30
|
|
|||
|
GW216PP2
|
Square
|
57.2
|
140
|
63.5
|
30
|
|
|||
|
GW226PPB2
|
Square
|
57.2
|
140
|
63.5
|
30
|
|
|||
