Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
JIAGU
-
Model Number:
-
HY595D 595HD 583H
-
Type:
-
one-component
-
Product name:
-
heat conductive silicone glue
-
Material:
-
Neutral silicone
-
Color:
-
White
-
Feature:
-
Eco-friendly
-
Applicable temperature (℃):
-
-60~260
-
Shelf life:
-
9 Months
-
Application:
-
Electronic Components
-
Certificate:
-
REACH CE
-
Product Keywords:
-
Thermally Conductive adhesive
-
Packing:
-
100ml / as your request
Quick Details
-
CAS No.:
-
9016-00-6
-
Other Names:
-
heat conductive silicone glue
-
MF:
-
C2H6OSi
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
JIAGU
-
Model Number:
-
HY595D 595HD 583H
-
Type:
-
one-component
-
Product name:
-
heat conductive silicone glue
-
Material:
-
Neutral silicone
-
Color:
-
White
-
Feature:
-
Eco-friendly
-
Applicable temperature (℃):
-
-60~260
-
Shelf life:
-
9 Months
-
Application:
-
Electronic Components
-
Certificate:
-
REACH CE
-
Product Keywords:
-
Thermally Conductive adhesive
-
Packing:
-
100ml / as your request
Product Description
Product I
ntroduction
Jiagu thermal conductive silicone rubber sealant, referred to as RTV-1 sealant, has the advantages of no solvent, no isocyanate, anti-pollution after curing, environmental protection, excellent heat resistance and anti-aging ability. It’s suitable for heat conduction sealing of mechanical equipment and electronic components.
Packing specification
Aluminum tube: 100ml/tube, 100tubes/carton
Cartridge packaging: 310ml/tube, 50tubes /carton
Jiagu thermal conductive silicone rubber sealant, referred to as RTV-1 sealant, has the advantages of no solvent, no isocyanate, anti-pollution after curing, environmental protection, excellent heat resistance and anti-aging ability. It’s suitable for heat conduction sealing of mechanical equipment and electronic components.
This product meets environmental protection requirements, does not contain harmful substances in GB18583 "Limits of Hazardous Substances in Adhesives for Interior Decoration Materials", and complies with
EU ROHS and REACH
environmental protection standards.
Applications
Suitable for heat conduction sealing and bonding of various electronic components; HY583H is non-corrosive to materials such as polycarbonate (PC) and copper.
Suitable for heat conduction sealing and bonding of various electronic components; HY583H is non-corrosive to materials such as polycarbonate (PC) and copper.
Product Features
1. Excellent thermal conductivity.
2. Solvent-free, PVC-free, isocyanate-free, non-toxic, neutral and environmentally friendly.
3. Excellent thixotropy and extrudability, wide applicable temperature range.
4. It has excellent bonding properties to most metals such as aluminum, painted steel plates and PVC, ABS, and polyester materials.
5. Excellent weather resistance, aging resistance, superior tensile and compression resilience.
1. Excellent thermal conductivity.
2. Solvent-free, PVC-free, isocyanate-free, non-toxic, neutral and environmentally friendly.
3. Excellent thixotropy and extrudability, wide applicable temperature range.
4. It has excellent bonding properties to most metals such as aluminum, painted steel plates and PVC, ABS, and polyester materials.
5. Excellent weather resistance, aging resistance, superior tensile and compression resilience.
Packing specification
Aluminum tube: 100ml/tube, 100tubes/carton
Cartridge packaging: 310ml/tube, 50tubes /carton
Technical Parameters
|
Model
|
HY595D
|
HY595HD
|
HY583H
|
||
|
Appearance
|
White paste de-oxime type
|
White paste de-oxime type
|
Grey paste de-alcoholization type
|
||
|
Density (g/cm3)
|
1.5±0.2
|
1.5±0.2
|
1.5±0.2
|
||
|
Sag (mm)
|
≤3
|
≤3
|
≤3
|
||
|
Surface drying time (min)
|
20~40
|
20~40
|
5~30
|
||
|
Curing speed (min /24h)
|
3.0
|
3.0
|
3.0
|
||
|
Tensile shear strength (Mpa)
|
1.0
|
1.0
|
0.8
|
||
|
Hardness (Shore A)
|
30~50
|
30~50
|
30~50
|
||
|
Volume resistance (Ω•cm)
|
1.2×10 12
|
1.2×10 12
|
1.2×10 12
|
||
|
Thermal conductivity (W/m•K)
|
0.7~0.9
|
1.0~1.2
|
1.6~2.0
|
||
|
Applicable temperature (℃)
|
-60~260
|
|
|
||
Packaging specification
