Quick Details
-
Power:
-
7Kw
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
LTMG
-
Maximum Digging Height:
-
1600mm
-
Maximum Digging Depth:
-
1715mm
-
Machine Weight:
-
800 kg
-
Max Digging Radius:
-
3065mm
-
Rated Speed:
-
1.5km/h
-
Marketing Type:
-
New Product
-
Product type:
-
Crawler Excavator
-
Digging bucket capacity:
-
0.023cbm
-
Max. Digging height:
-
2600 mm
-
Max.digging depth:
-
1715 mm
-
Dimension:
-
2840*880*2220 mm
-
After Warranty Service:
-
Video technical support
-
bucket capacity:
-
0.035cbm
-
Product name:
-
Mini excavator
-
Keywords:
-
small excavator
-
Engine Model:
-
accept customized
Quick Details
-
Operating Weight:
-
0.8 TON, 1.8Ton, 1.2ton, 1 ton
-
Bucket capacity:
-
0.023m3
-
Engine Brand:
-
KOOP
-
Power:
-
7Kw
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
LTMG
-
Maximum Digging Height:
-
1600mm
-
Maximum Digging Depth:
-
1715mm
-
Machine Weight:
-
800 kg
-
Max Digging Radius:
-
3065mm
-
Rated Speed:
-
1.5km/h
-
Marketing Type:
-
New Product
-
Product type:
-
Crawler Excavator
-
Digging bucket capacity:
-
0.023cbm
-
Max. Digging height:
-
2600 mm
-
Max.digging depth:
-
1715 mm
-
Dimension:
-
2840*880*2220 mm
-
After Warranty Service:
-
Video technical support
-
bucket capacity:
-
0.035cbm
-
Product name:
-
Mini excavator
-
Keywords:
-
small excavator
-
Engine Model:
-
accept customized
Advantages
|
Model
|
LTE08
|
LTE10H
|
LTE12
|
LTE15
|
LTE17
|
LTE20
|
|
Operating Weight(Kg)
|
750
|
950
|
1100
|
1350
|
1600
|
1850
|
|
Engine Model
|
KOOP192F
|
KOOP192F
|
KOOP192F
|
LaidongLD380
|
LaidongLD385
|
Changchai390
|
|
Rated Power(Kw)
|
8.6kw/12hp
|
10.3kw/14hp
|
10.3kw/14hp
|
19.1kw/26hp
|
29Kw/39hp
|
22kw/30hp
|
|
Bucket Capacity(m³)
|
0.02
|
0.02
|
0.02
|
0.03
|
0.04
|
0.045
|
|
Bucket Width(mm)
|
300
|
400
|
400
|
400
|
400
|
400
|
|
Max Digging Force(Kn)
|
9.5
|
10.3
|
10.3
|
12
|
14
|
15.2
|
|
System Working Pressure(Mpa)
|
16
|
18
|
18
|
18
|
18
|
20
|
|
Swing Speed(rpm)
|
12
|
12
|
12
|
12
|
12
|
10
|
|
Traveling Speed(km/h)
|
2
|
2
|
2
|
2.1
|
2.8
|
2.8
|
|
Gradeability(°)
|
30
|
30
|
30
|
30
|
35
|
35
|
|
Ground Pressure(Kpa)
|
20
|
22
|
22
|
25
|
25
|
30
|
|
Max. Digging Distance(mm)
|
2450
|
2450
|
2450
|
2500
|
2500
|
2500
|
|
Max. Digging Depth(mm)
|
1200
|
1320
|
1320
|
1800
|
1900
|
2150
|
|
Max. Digging Height(mm)
|
2430
|
2500
|
2500
|
2590
|
2820
|
2950
|
|
Max. Dumping Height(mm)
|
1650
|
1820
|
1820
|
1850
|
2000
|
2230
|
|
Min. Turning Radius(mm)
|
1100
|
1190
|
1190
|
1190
|
1190
|
1190
|
|
Overall Length(mm)
|
2200
|
2200
|
2200
|
2200
|
2250
|
2300
|
|
Overall Width(mm)
|
720
|
940
|
940
|
1100
|
1100
|
1150
|
|
Overall Height(mm)
|
1150
|
2150
|
2150
|
2170
|
2200
|
2150
|
|
Min. Ground Clearance(mm)
|
380
|
380
|
380
|
380
|
380
|
385
|
|
Track Ground Length(mm)
|
1140
|
1200
|
1200
|
1180
|
1370
|
1500
|
|
Track Width(mm)
|
150
|
180
|
180
|
180
|
180
|
200
|
