Quick Details
-
Material:
-
stainless steel or zinc alloy
-
Type:
-
emergency exit device
-
Installation:
-
Surface mounted for ease of installation
-
Max Door Weight:
-
20kg
-
Certification:
-
UL Listed
-
Factory Quality Control:
-
ISO 9001:2000
-
Endurance test:
-
over 500,000 times
-
Fire Rated:
-
UL 10 C Fire Rated
-
Suitable for:
-
Wooden door, Metal door, fire rated door etc
Quick Details
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
Zonle Doors
-
Product Name:
-
panic exit device aluminium alloy of fire door
-
Material:
-
stainless steel or zinc alloy
-
Type:
-
emergency exit device
-
Installation:
-
Surface mounted for ease of installation
-
Max Door Weight:
-
20kg
-
Certification:
-
UL Listed
-
Factory Quality Control:
-
ISO 9001:2000
-
Endurance test:
-
over 500,000 times
-
Fire Rated:
-
UL 10 C Fire Rated
-
Suitable for:
-
Wooden door, Metal door, fire rated door etc
Product Description
Specification
|
Item NO.
|
JSA1720S
|
|
Material
|
Iron body, Alu cover
|
|
Finish
|
Silver painted
|
|
Push bar size
|
500mm
|
|
Length
|
1040mm
|
|
Bolt
|
Zinc
|
|
End Cap
|
Plastic
|
|
Striker
|
Zinc
|
|
Certificate
|
UL305, Chinese domestic fire rated 1.5H
|
|
UL NO.
|
SA44924
|
|
Item NO. on UL Certificate
|
L500P
Rim type, With security bolt and dogging hole. Popular for Asia and Middle east market. Fixed with C1,C2,C3 cylinder, 016,026,017P or 017S outside trim lock |
|
Package details
|
1pc per box, box size is 106x16.3x8cm GW:3.6KGS 6pcs per carton, carton size is 107.5x34x26cm GW: 23kgs
|
|
Accessory
|
1 end cap with mounting plate, 1 striker, 1 screws bag
|
Certifications
Why choose Jsaian Panic Bar Device
1.
UL certificate
, CE certificate with fire resistant test and CCCF certificate.
2. Warranty 2 years with 200,000 circle service life. Service life testing even can reach more then 500,000 circles.
3. The biggest panic exit bar device workshop in China. Monthly production capacity is over 20,000 pcs.
4. Panic exit device warranty past the salt spray test more then 72 hours. Push bar surface there’s no damage after 96 hour salt spray test by our selves.
5. Material Panic exit device use 1.2 mm thickness stainless steel 304 or 1.2 mm Cold rolled steel. Surface can finished with polish, brushed can high temperature spray powder paint.
2. Warranty 2 years with 200,000 circle service life. Service life testing even can reach more then 500,000 circles.
3. The biggest panic exit bar device workshop in China. Monthly production capacity is over 20,000 pcs.
4. Panic exit device warranty past the salt spray test more then 72 hours. Push bar surface there’s no damage after 96 hour salt spray test by our selves.
5. Material Panic exit device use 1.2 mm thickness stainless steel 304 or 1.2 mm Cold rolled steel. Surface can finished with polish, brushed can high temperature spray powder paint.
Packing & Delivery
Inside PE film+ bubble bag/ outside strong carton
