Custom TFT LCD 0.96-32" ips screen panel 3.5 4.3 5 5.0 7.0 8.0 10.1 inch small touch tft display lcd module

FOB Reference Price: Get Latest Price

≥1 Pieces

US $28

≥100 Pieces

US $18.88

≥1000 Pieces

US $10.3

≥10000 Pieces

US $6.2

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: STARTEK

Resolution:: Mini 80x160, up to FHD 1920x1080

Interface:: MCU/SPI/RGB/MIPI/LVD//UART

Brightness:: 450~1000nits

Touch panel:: RTP or CTP are optional

Viewing Angle:: 85/85/85/85 (Typ.)(CR 10) (L/R/U/D)

LCD Type:: TFT IPS

Panel Size:: 1.33 inch~10.1 inch

MOQ:: 1PCS

Warranty:: 1 Year

Quality:: Strictly Tested for Medical & Industrial applications

Quick Details

Type:: TFT

Display Size:: 0.96 inch ~ 10.1 inch

Supplier Type:: Manufacturer

Place of Origin:: Guangdong, China

Brand Name:: STARTEK

Resolution:: Mini 80x160, up to FHD 1920x1080

Interface:: MCU/SPI/RGB/MIPI/LVD//UART

Brightness:: 450~1000nits

Touch panel:: RTP or CTP are optional

Viewing Angle:: 85/85/85/85 (Typ.)(CR 10) (L/R/U/D)

LCD Type:: TFT IPS

Panel Size:: 1.33 inch~10.1 inch

MOQ:: 1PCS

Warranty:: 1 Year

Quality:: Strictly Tested for Medical & Industrial applications

What is IPS display ?

^{1.8" 2.0" 2.4" 2.8" 3.0" 3.5" 4.0" 4.3" 5.0" 5.5" 7.0" 8.0" 10.1" IPS TFT LCD Module Touch Screen Panel High Brightness Display}

IPS (in-plane switching) is a screen technology for liquid-crystal displays (LCDs). It was designed to solve the main limitations of the twisted nematic field effect (TN) matrix LCDs which were prevalent in the late 1980s. These limitations included strong viewing angle dependence and low-quality color reproduction.

Target Applications:

features:
* Optimal readability in sunlight
* Ideal for outdoor use
* Energy saving and therefore ideal for battery powered devices

Application areas:
* Agriculture & construction machinery
* marine, Automotive
* outdoor devices

Size	Part No.	Resolution	Brightness cd/㎡	Temperature ℃	Interface （ Optional ）	Touch/Notes ( Optional )
1.3	KD013QVFMN002	240x240	450	-20~70	MCU/SPI/RGB	Round LCD
1.5	KD015QVFMN001	240x240	255	-20~70	MCU/SPI/RGB	Square LCD
1.77	KD018QVFMN010	240x320	450	-20~70	MCU/SPI/RGB	RTP/CTP
2.0	KD020QVFMA009	240x320	450	-20~70	MCU/SPI/RGB	RTP/CTP
2.0	KD020LQFMA014	320x240	600	-20~70	MCU/SPI/RGB	Landscape
2.2	KD022QVFMD014	240x320	450	-20~70	MCU/SPI/RGB	RTP/CTP
2.4	KD024QVFIA073	240x320	550	-20~70	MCU/SPI/RGB /MIPI	RTP/CTP
2.6	KD026QVFMD007	240x320	350	-20~70	MCU/SPI/RGB	RTP/CTP
2.8	KD028FM-1	240x320	700	-20~70	MCU/SPI/RGB	RTP/CTP
3.0	KD030NHFIN015	360x640	350	-20~70	MIPI	CTP
3.1	KD031WVFID001	480x800	350	-20~70	MIPI	CTP
3.5	KD035LQFPA093-01	320x240	920	-20~70	RGB	Landscape
3.5	KD035QVFMA064	240x320	450	-30~85	MCU/SPI/RGB	RTP/CTP
3.5	KD035HVFMD057	320x480	500	-20~70	MCU/SPI/RGB	RTP/CTP
3.5	KD035VGFPA094	480x640	420	-20~70	SPI+RGB	CTP
3.5	KD035WVFID121	480x800	400	-20~70	MIPI	CTP
4.0	KD040WVFBD023	480x800	500	-20~70	MCU/SPI/RGB	RTP/CTP
4.0	KD040WXFPD014	480x480	1000	-20~70	MCU/SPI/RGB	Square LCD
4.3	KD043WQFPA042	480x272	900	-30~85	RGB	RTP/CTP
4.3	KD043WVFPA034	800x480	500	-30~85	RGB	RTP/CTP
4.3	KD043WVFPA022	480x800	450	-20~70	MCU/SPI/RGB/MIPI	RTP/CTP
5.0	KD050WVFPA029	800x480	650	-20~70	RGB	RTP/CTP
5.0	KD050FWFPA011	480x854	520	-20~70	SPI+RGB	RTP/CTP
5.0	KD050HDFIA020	720x1280	520	-20~70	MIPI	CTP
5.5	KD055FHFID005-02	1080x1920	350	-20~70	MIPI	CTP
6.0	KD060HDFID001	720x1440	560	-20~70	MIPI	CTP
6.7	KD067WSFLA001	1920x1080	800	-20~70	LVDS	Landscape
7.0	KD070WVFLA011-02	800x480	1000	-20~70	LVDS/RGB	RTP/CTP
7.0	KD070HDFLA013	1024x600	600	-20~70	LVDS/RGB	RTP/CTP
8.0	KD080WXFID008	800x1280	280	-20~70	MIPI	CTP
8.0	KD080C-5	1024x768	550	-20~70	LVDS	CTP
10.1	KD101FM-1	1280x800	350	-20~70	LVDS	CTP
10.1	KD101WXFID013	800x1280	350	-20~70	MIPI	CTP
10.1	KD101UXFID008	1200x1920	250	-20~70	MIPI	CTP
10.1	KD101UXFLD009	1920x1200	400	-20~70	LVDS	CTP
13.3	KD133FHFED001	1920x1080	310	-20~70	eDP	CTP
