Quick Details
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
15000 KG
-
Product Name:
-
Ball Mill Machine
-
Color:
-
Customers' Requirements
-
Application:
-
Stone Grinding Plant
-
After Sale Service:
-
Engineer Overseas Service
-
Price:
-
Competetive (Can Negotiate)
-
Factory:
-
50,000 Square Meters Closed Workshops
-
Installation and Trial:
-
We Can Send Engineer for Guidance
-
Capacity:
-
1-230t/h
-
Certification:
-
ISO9001 CE, ISO9001:14000
-
Advantage:
-
Timely Delivery and Installation, Fast Technical Support
Quick Details
-
Capacity(t/h):
-
1-230t/h
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
ZOOMJO
-
Dimension(L*W*H):
-
Customizable
-
Weight:
-
15000 KG
-
Product Name:
-
Ball Mill Machine
-
Color:
-
Customers' Requirements
-
Application:
-
Stone Grinding Plant
-
After Sale Service:
-
Engineer Overseas Service
-
Price:
-
Competetive (Can Negotiate)
-
Factory:
-
50,000 Square Meters Closed Workshops
-
Installation and Trial:
-
We Can Send Engineer for Guidance
-
Capacity:
-
1-230t/h
-
Certification:
-
ISO9001 CE, ISO9001:14000
-
Advantage:
-
Timely Delivery and Installation, Fast Technical Support
Small Miner Investment Gold Continuous Gypsum Ball Mill Machine Ball Milling Plant Stone Grinding
Product Description
1-20t/h small Wet / Dry grinding ball mill on sale with 2023 Factory Price
Gold Ball Milling Plant
There are two kinds of ball mill, grid type and overflow type due to different ways of discharging material.
Ball mill is mainly used to grind materials in mineral, cement, refractory, chemical industry, etc. Ball mill has dry and wet ways.
When wet ball mill works, certain water and other liquid will be added into materials to increase flow ability of materials, so the capacity is increased. When dry ball mill works, capacity is affected because material flow ability is reduced, so absorbing wind device is needed on the outlet of ball mill, and then negative pressure is formed in the ball mill to increase flow ability of material, so the capacity is increased etc.
Just leave us your whatsapp or email, we send the latest price list to you.
Whenever, 7X24 hours online service is waiting for you.
Hot-sale in many countries: Zimbabwe, Mozambique, Zambia, South Africa, Kenya, Philippines, Indonesia, Vietnam, Uganda, Ethiopia,Tanzania, Peru, Mexico.
Working Flow
The ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
1.Liner of ball mill is made of high-quality wear resistant material with high strength, wear resistance and long working life.
2.Product fineness is adjustable, uniform and high qualified.
3.Large capacity and crushing ratio, good sealing performance. It can be adapted to different working conditions.
4.High grinding efficiency, low energy consumption.
Product Details
Our Advantages
Our ball mills have been welcomed by many customers, and they have given very high evaluations to our products, and customers continue to order ball mills produced by our company.
Our senior technical engineers can provide solutions to the problems you encounter through online or quickly arrive at your production site at any time, and our experienced installation team can quickly and efficiently build and install your cement line factory, allowing you Produce cement products that meet the requirements in the shortest time, allowing you to see benefits in the shortest time.
|
Model
|
Drum Size (m)
|
Speed (r/min)
|
Ball Weigh(t)
|
Feed Size (mm)
|
Output Size (mm)
|
Capacity (t/h)
|
|
MQZ1224
|
1.2X2.4
|
31
|
4.8
|
0-20
|
0.07-0.6
|
0.4-6.8
|
|
MQZ1245
|
1.2X4.5
|
31
|
5.2
|
0-20
|
0.07-0.6
|
1.6-12
|
|
MQZ1530
|
1.5X3.0
|
27.5
|
8.1
|
0-25
|
0.07-0.4
|
2.9-16.5
|
|
MQZ1557
|
1.5X5.7
|
29.2
|
15
|
0-25
|
0.07-0.4
|
4-25
|
|
MQZ1645
|
1.6X4.5
|
27.5
|
14
|
0-25
|
0.07-0.4
|
4-24
|
|
MQZ1836
|
1.8X3.6
|
23.9
|
11
|
0-25
|
0.07-0.4
|
8-40
|
|
MQZ1864
|
1.6X6.4
|
23.9
|
18.5
|
0-25
|
0.07-0.4
|
8-60
|
|
MQZ2130
|
2.1X3.0
|
23.8
|
19.8
|
0-25
|
0.07-0.4
|
6.5-36
|
|
MQZ2136
|
2.1X3.6
|
23.8
|
27
|
0-25
|
0.07-0.4
|
8-61
|
|
MQZ2265
|
2.2X6.5
|
21.6
|
28
|
0-25
|
0.07-0.4
|
8-35
|
|
MQZ2430
|
2.4X3.0
|
22
|
22.5
|
0-25
|
0.07-0.4
|
7-92
|
|
MQZ2436
|
2.4X3.6
|
22
|
28
|
0-25
|
0.07-0.4
|
7-95
|
|
MQZ2465
|
2.4X6.5
|
22
|
36
|
0-25
|
0.07-0.4
|
7-110
|
|
MQZ2736
|
2.7X3.6
|
21.9
|
39
|
0-25
|
0.07-0.4
|
13-140
|
|
MQZ2745
|
2.7X4.5
|
21.9
|
43
|
0-25
|
0.07-0.4
|
13-150
|
|
MQZ2836
|
2.8X3.6
|
20
|
42
|
0-25
|
0.07-0.4
|
15-140
|
|
MQZ3060
|
3.0X6.0
|
19
|
70
|
0-25
|
0.07-0.4
|
100-145
|
|
MQZ3245
|
3.2X4.5
|
18.6
|
65
|
0-25
|
0.07-0.4
|
100-145
|
|
MQZ3260
|
3.2X6.0
|
18.6
|
86
|
0-25
|
0.07-0.4
|
120-150
|
|
MQZ3645
|
3.6X4.5
|
17.8
|
90
|
0-25
|
0.07-0.4
|
120-220
|
|
MQZ3660
|
3.6X6.0
|
17.8
|
120
|
0-25
|
0.07-0.4
|
50-230
|
Packaging & Shipping
Packaging Details: We will make different packaging according to different machine sizes. Standard international export packing, container, wooden box. Delivery Time: We will customize according to the actual needs of customers. Senior designers start to design the plan. After receiving the deposit, we will complete the delivery within 20 to 30 working days.
