Moduel
|
FSM290M-60
|
FSM295M-60
|
FSM300M-60
|
FSM305M-60
|
|||
|
Rated Maximum Power at STC
|
290
|
295
|
300
|
305
|
|||
|
Open Circuit Voltage(Voc/V)
|
38.9
|
39.6
|
39.8
|
40.0
|
|||
|
Maximum Power Voltage(Vmp/V)
|
32.2
|
32.5
|
32.6
|
32.9
|
|||
|
Short Circuit Current(Isc/A)
|
9.66
|
9.68
|
9.77
|
9.85
|
|||
|
Maximum Power Current(Imp/A)
|
9.01
|
9.08
|
9.19
|
9.28
|
|||
|
Module Efficiency(%)
|
17.7
|
18.0
|
18.3
|
18.6
|
|||
|
Power Tolerance
|
-0~+3%
|
|
|
|
|||
|
Standard Test Condition(STC)
|
Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5
|
|
|
|
|||
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
|
Payment Terms
|
T/T
|
EXW
|
30% T/T in advance, paid the balance before shipment
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR(C&F)
|
30% T/T in advance, paid the balance against copy of B/L (
Not Suitable for Solar System Orders
)
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
|
DDP
|
|
|
|||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight (
Not Suitable for Solar System Orders
)
|
|
|
|||
|
|
West Union
|
Amount lower than 5000usd
|
|
|
|||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
|
|||
