Quick Details
-
Voltage:
-
380v/3phase/50hz, 220v/380v/3phase/50hz
-
Disc Dia.:
-
Customers Request
-
No Load Speed:
-
0.25m/s
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Enshine
-
Model Number:
-
Enshine4500A
-
Warranty:
-
12 months
-
Product name:
-
furniture paint booth
-
Color:
-
Red/blue/white/orange or customized
-
Usage:
-
Spray Booth for Furniture
-
Wall Panel:
-
EPS or Rock Wool
-
Heating System:
-
Infrared Heating
-
Filters:
-
Ceiling and Flooring Filters
-
MOQ:
-
1 Set
-
Certificate:
-
CE and ISO
-
Lighting System:
-
LED Light
-
Control system:
-
Standard Control System
Quick Details
-
Power:
-
24.80kw
-
External Size:
-
12000*5000*3000mm(L*W*H)
-
Internal Size:
-
11850*4900*2600(L*W*H)
-
Voltage:
-
380v/3phase/50hz, 220v/380v/3phase/50hz
-
Disc Dia.:
-
Customers Request
-
No Load Speed:
-
0.25m/s
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Enshine
-
Model Number:
-
Enshine4500A
-
Warranty:
-
12 months
-
Product name:
-
furniture paint booth
-
Color:
-
Red/blue/white/orange or customized
-
Usage:
-
Spray Booth for Furniture
-
Wall Panel:
-
EPS or Rock Wool
-
Heating System:
-
Infrared Heating
-
Filters:
-
Ceiling and Flooring Filters
-
MOQ:
-
1 Set
-
Certificate:
-
CE and ISO
-
Lighting System:
-
LED Light
-
Control system:
-
Standard Control System
Specification
We can produce the
SIZE, COLOR, LOGO
as your request!
|
Overall inner Dimension (L*W*H)
|
12000*5000*3000 mm or customized
|
|
Painting Room Dimension (L*W*H)
|
6000*5000*3000 mm
or customized
|
|
Drying Room Dimension (L*W)
|
6000*5000*3000 mm
or customized
|
|
Incoming Door Dimension (W*H)
|
1900*2300 mm
|
|
Delivery Door Dimension (W*H)
|
1900*2300 mm
|
|
Air Capacity(m3/h)
|
20000
|
|
Air Speed(m/s)
|
0.2-0.3
|
|
Ventilation Rate(Times/Hour)
|
255
|
|
Fan Power(KW)
|
2*1.5kw 2*2.2KW
|
|
Wall Panels
|
Panels 50mm EPS colorful steel skin panel,
steel 0.4mm thick, 12kg/cbm and flame-resisting EPS,
tongue groove style, compound construction, anti-flame and heat-insulation.
|
|
Grilles
|
10#channel steel， 6M2
|
|
Lighting
|
4*4*36W lamp,Illuminance exceeding 750LUX, non explosive
|
|
Infrared Heating Tubes
|
24 pieces ×1 KW infrared light heater ,anti-explosion
|
|
Generator Setting Type
|
Upper intake air
|
|
Intake Air Fan For painting room
|
2×1.5KW double-intake centrifugal fans, air capacity: 20000m³/h
|
|
Exhaust Fan For painting room
|
2×2.2 KW with water curtain booth.
|
|
Filter System
|
Intake air: pre-filter, high efficiency filter(ceiling filter)
Exhaust air: water curtain filtering
|
Products Description
Details Images
Cases
1. Presale service: The best suggestion will be made for you;
2. Every spray booth will be tested before shipment;
3. Technical support, Installation support, Using support within 24 hours.
2. Every spray booth will be tested before shipment;
3. Technical support, Installation support, Using support within 24 hours.
Also our engineers could be at your side to help you;
4. The warranty time of all spray booth is 12 months;
5. Several spare parts of spray booth will be free for you.
4. The warranty time of all spray booth is 12 months;
5. Several spare parts of spray booth will be free for you.
