Diameter
|
φ 200mm
|
φ 300mm
|
|
|
LED Type
|
High Brightness SMD
|
|
|
|
Color-Wavelength
|
Red 615~630nm, Amber 583~595nm, Green 500~510nm
|
|
|
|
Optical Performance
|
Conform to EN12368 standard
|
|
|
|
View Distance
|
≥300m
|
≥500m
|
|
|
Input Voltage
|
AC85-265V, AC26-55V, DC10-30V
|
|
|
|
Power Factor
|
＞ 0.9
|
|
|
|
EMC
|
According to EN50293
|
|
|
|
Power Consumption
|
R ≤ 7W
|
R ≤ 12W
|
|
|
|
Y ≤ 9W
|
Y ≤ 14W
|
|
|
|
G ≤ 10W
|
G ≤ 15W
|
|
|
Working Temperature
|
-40℃ ~ +80℃ (Class A,B,C acc. To EN12368)
|
|
|
|
Ingress Protection
|
IP55 acc. to EN 60529
|
|
|
|
Impact Resistance
|
Class IR 3 acc. To EN60598-1
|
|
|
|
Material of Lens/Housing
|
UV-stabilized polycarbonate
|
|
|
|
Color of Housing
|
Black - standard, fir-green/yellow upon qty request
|
|
|
